– 114 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
************************************************************
* 1-658-576-11 SENSOR BOARD
*************
< PHOTO INTERRUPTER >
IC702 8-749-924-18 PHOTO INTERRUPTER RPI-1391
IC703 8-749-924-30 PHOTO REFLECTOR GP2S28
< RESISTOR >
R701 1-249-416-11 CARBON 820 5% 1/4W
R702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* 1-664-024-11 TC SW BOARD
************
< CONNECTOR >
CN607 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D634 8-719-063-92 LED SLR325MC-M-T31-NP (· (DECK B))
D635 8-719-063-92 LED SLR325MC-M-T31-NP (ª (DECK B))
D636 8-719-063-91 LED SLR325DC-P-T32 (P PAUSE)
D637 8-719-063-93 LED SLR325VC-N-T32 (r REC)
D638 8-719-063-92 LED SLR325MC-M-T31-NP (· (DECK A))
D639 8-719-063-92 LED SLR325MC-M-T31-NP (ª (DECK A))
< TRANSISTOR >
Q617 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q618 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q619 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R726 1-249-403-11 CARBON 68 5% 1/4W
R727 1-247-807-31 CARBON 100 5% 1/4W
R728 1-249-407-11 CARBON 150 5% 1/4W
R729 1-249-407-11 CARBON 150 5% 1/4W
R730 1-249-409-11 CARBON 220 5% 1/4W
R731 1-249-411-11 CARBON 330 5% 1/4W
R732 1-249-413-11 CARBON 470 5% 1/4W
R733 1-249-415-11 CARBON 680 5% 1/4W
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-419-11 CARBON 1.5K 5% 1/4W
R736 1-249-421-11 CARBON 2.2K 5% 1/4W
R737 1-247-843-11 CARBON 3.3K 5% 1/4W
R738 1-249-427-11 CARBON 6.8K 5% 1/4W
R739 1-249-431-11 CARBON 15K 5% 1/4W
R740 1-247-807-31 CARBON 100 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
R742 1-247-807-31 CARBON 100 5% 1/4W
R743 1-249-409-11 CARBON 220 5% 1/4W
R744 1-247-807-31 CARBON 100 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S655 1-762-752-11 SWITCH, TACTILE (· (DECK B))
S656 1-762-752-11 SWITCH, TACTILE (ª (DECK B))
S657 1-762-752-11 SWITCH, TACTILE () (DECK B))
S658 1-762-752-11 SWITCH, TACTILE (0 (DECK B))
S659 1-762-752-11 SWITCH, TACTILE (p (DECK B))
S660 1-762-752-11 SWITCH, TACTILE (P PAUSE)
S661 1-762-752-11 SWITCH, TACTILE (r REC)
S662 1-762-752-11 SWITCH, TACTILE (CD SYNCHRO)
S663 1-762-752-11 SWITCH, TACTILE (HIGH SPEED DUBBING)
S664 1-762-752-11 SWITCH, TACTILE () (DECK A))
S665 1-762-752-11 SWITCH, TACTILE (0 (DECK A))
S666 1-762-752-11 SWITCH, TACTILE (p (DECK A))
S667 1-762-752-11 SWITCH, TACTILE (· (DECK A))
S668 1-762-752-11 SWITCH, TACTILE (ª (DECK A))
************************************************************
* 1-664-026-11 TRANS BOARD
************
< CAPACITOR >
C901 1-136-165-00 FILM 0.1uF 5% 50V
C902 1-136-165-00 FILM 0.1uF 5% 50V
C903 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN901 1-564-522-11 PLUG, CONNECTOR 7P
* CN902 1-564-518-11 PLUG, CONNECTOR 3P
CN903 1-564-321-00 PIN, CONNECTOR 2P
< FUSE >
! F901 1-532-388-31 FUSE, TIME-LAG (T2A/250V)
! F902 1-532-504-31 FUSE, TIME-LAG (T4A/250V)
(EXCEPT EA, MY, TH)
< FUSE HOLDER >
FH901 1-533-233-21 HOLDER, FUSE
FH902 1-533-233-21 HOLDER, FUSE
FH951 1-533-233-21 HOLDER, FUSE (EXCEPT EA, MY, TH)
FH952 1-533-233-21 HOLDER, FUSE (EXCEPT EA, MY, TH)
< RESISTOR >
! R901 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R902 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R903 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R904 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< SWITCH >
! S901 1-572-675-11 SWITCH, POWER VOLTAGE CHANGE
(VOLTAGE SELECTOR) (EXCEPT EA, MY, TH)
************************************************************
SENSOR TC SW TRANS
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
