Ref. No. Part No. Description Remark
! 114 1-569-007-11 ADAPTOR, CONVERSION 2P (IA)
! 114 1-569-008-11 ADAPTOR, CONVERSION 2P (MY, SP, TW)
! 114 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
119 1-782-653-11 WIRE (FLAT TYPE) (13 CORE)
257 1-452-925-11 MAGNET ASSY
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
! 301 8-820-020-01 OPTICAL PICK-UP KSS-213D/Q-NP
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECK A)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M701 A-4672-004-A MOTOR ASSY (TURN)
M801 A-4672-004-A MOTOR ASSY (SLIDE)
M901 1-698-792-11 FAN, DC
S811 1-473-335-11 ENCODER, ROTARY
(BU, TRAY, ADDRESS DET)
! T901 1-431-304-11 TRANSFORMER, POWER
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-871-01 SCREW +BVTT 3X6 (S)
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#4 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#5 7-621-775-10 SCREW +B 2.6X4
#6 7-621-255-15 SCREW +P 2X3
#7 7-685-533-19 SCREW +BTP 2.6X6 TYPE 2 N-S
#8 7-685-131-19 SCREW +BTP 2.6X4 TYPE 2 N-S
#9 7-685-862-09 SCREW +BVTT 2.6X6 (S)
#10 7-685-534-19 SCREW +BTP 2.6X8 TYPE 2 N-S
#11 7-623-921-01 RING, RETAINING, CAPSTAN
#12 7-621-775-00 SCREW +B 2.6X3
#13 7-685-872-09 SCREW +BVTT 3X8 (S)
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
