Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
144
HCD-FLX9W
FRONT REAR AMP
A-4728-418-A FRONT REAR AMP BOARD, COMPLETE (TH)
A-4730-385-A FRONT REAR AMP BOARD, COMPLETE
(EXCEPT TH)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C401 1-126-964-11 ELECT 10uF 20% 50V
C402 1-162-290-31 CERAMIC 470PF 10% 50V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-126-947-11 ELECT 47uF 20% 35V
C405 1-136-497-81 FILM 0.1uF 5% 50V
C406 1-136-497-81 FILM 0.1uF 5% 50V
C407 1-126-965-11 ELECT 22uF 20% 50V
C408 1-126-965-11 ELECT 22uF 20% 50V
C420 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-967-11 ELECT 47uF 20% 50V
C422 1-126-967-11 ELECT 47uF 20% 50V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-162-290-31 CERAMIC 470PF 10% 50V
C433 1-162-282-31 CERAMIC 100PF 10% 50V
C434 1-126-947-11 ELECT 47uF 20% 35V
C435 1-136-497-81 FILM 0.1uF 5% 50V
C436 1-136-497-81 FILM 0.1uF 5% 50V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-162-290-31 CERAMIC 470PF 10% 50V
C453 1-162-282-31 CERAMIC 100PF 10% 50V
C454 1-126-947-11 ELECT 47uF 20% 35V
C455 1-136-497-81 FILM 0.1uF 5% 50V
C456 1-136-497-81 FILM 0.1uF 5% 50V
C457 1-126-965-11 ELECT 22uF 20% 50V
C458 1-126-965-11 ELECT 22uF 20% 50V
C470 1-162-294-31 CERAMIC 0.001uF 10% 50V
C471 1-126-967-11 ELECT 47uF 20% 50V
C481 1-126-964-11 ELECT 10uF 20% 50V
C482 1-162-290-31 CERAMIC 470PF 10% 50V
C483 1-162-282-31 CERAMIC 100PF 10% 50V
C484 1-126-947-11 ELECT 47uF 20% 35V
C485 1-136-497-81 FILM 0.1uF 5% 50V
C486 1-136-497-81 FILM 0.1uF 5% 50V
C491 1-164-159-11 CERAMIC 0.1uF 50V
C492 1-164-159-11 CERAMIC 0.1uF 50V
C493 1-128-550-11 ELECT 2200uF 20% 50V
C494 1-128-550-11 ELECT 2200uF 20% 50V
< CONNECTOR >
CN402 1-774-743-21 CONNECTOR, BOARD TO BOARD 18P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D421 8-719-991-33 DIODE 1SS133T-77
D431 8-719-991-33 DIODE 1SS133T-77
D432 8-719-991-33 DIODE 1SS133T-77
D451 8-719-991-33 DIODE 1SS133T-77
D452 8-719-991-33 DIODE 1SS133T-77
D481 8-719-991-33 DIODE 1SS133T-77
D482 8-719-991-33 DIODE 1SS133T-77
D491 6-500-249-01 DIODE D15XB20
< IC >
IC401 8-749-016-93 IC STK402-070S
IC431 8-749-016-93 IC STK402-070S
< TRANSISTOR >
Q401 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q419 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q420 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q421 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q422 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q423 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q431 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q451 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q471 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q472 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q481 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R401 1-249-417-11 CARBON 1K 5% 1/4W
R402 1-249-437-11 CARBON 47K 5% 1/4W
R403 1-249-413-11 CARBON 470 5% 1/4W
R404 1-249-437-11 CARBON 47K 5% 1/4W
0 R405 1-208-602-11 METAL 0.22 2W F
0 R406 1-208-602-11 METAL 0.22 2W F
R407 1-249-417-11 CARBON 1K 5% 1/4W
R408 1-249-431-11 CARBON 15K 5% 1/4W
R410 1-249-393-11 CARBON 10 5% 1/4W
0 R411 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R412 1-212-881-11 FUSIBLE 100 5% 1/4W F
R416 1-249-441-11 CARBON 100K 5% 1/4W
R417 1-249-441-11 CARBON 100K 5% 1/4W
R418 1-249-440-11 CARBON 82K 5% 1/4W
R419 1-249-429-11 CARBON 10K 5% 1/4W
0 R420 1-202-972-61 FUSIBLE 1 5% 1/4W F
R421 1-249-421-11 CARBON 2.2K 5% 1/4W
R422 1-249-433-11 CARBON 22K 5% 1/4W
R423 1-249-439-11 CARBON 68K 5% 1/4W
R424 1-249-426-11 CARBON 5.6K 5% 1/4W
R425 1-249-421-11 CARBON 2.2K 5% 1/4W
R426 1-249-421-11 CARBON 2.2K 5% 1/4W
R427 1-249-435-11 CARBON 33K 5% 1/4W
R428 1-249-431-11 CARBON 15K 5% 1/4W
R431 1-249-417-11 CARBON 1K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R433 1-249-415-11 CARBON 680 5% 1/4W
R434 1-249-437-11 CARBON 47K 5% 1/4W
0 R435 1-208-602-11 METAL 0.22 2W F
0 R436 1-208-602-11 METAL 0.22 2W F
R437 1-249-417-11 CARBON 1K 5% 1/4W
R438 1-249-433-11 CARBON 22K 5% 1/4W
R440 1-249-393-11 CARBON 10 5% 1/4W
R451 1-249-417-11 CARBON 1K 5% 1/4W
R452 1-249-437-11 CARBON 47K 5% 1/4W
R453 1-249-413-11 CARBON 470 5% 1/4W
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
