1-11
HDC1000/V2 (J, E)
Control Panel (HDC1000/1100)
No. Part No. SP Description
601
!
A-1124-075-A s MOUNTED CIRCUIT BOARD, CN-2603 (HDC1000(UCJ,J)/1100(J))
!
A-1177-500-A s MOUNTED CIRCUIT BOARD, CN-2603B (HDC1000(CE))
602
!
*
A-1159-990-A s MOUNTED CIRCUIT BOARD, AT-166G (GOLD)
!
*
A-1126-980-A s MOUNTED CIRCUIT BOARD, AT-166 (SILVER)
603
!
*
A-1163-069-A s MOUNTED CIRCUIT BOARD, SW-1233G (GOLD)
!
*
A-1124-074-A s MOUNTED CIRCUIT BOARD, SW-1233 (SILVER)
604 X-3167-562-1 o PAPER ASSY (WHITE)
X-3704-711-1 s PAPER HOLDER ASSY (BLACK)
605 X-3167-563-1 s KNOB (DIA.3) ASSY, VOLUME
606 X-3605-883-2 s SLOT,MEMORY STICK ASSY (ABS) (WHITE)
X-3704-707-1 s SLOT,MEMORY STICK ASSY (BLACK)
607
*
1-831-132-11 s CABLE, FLEXIBLE FLAT (30 CORE) (GOLD)
*
1-823-558-11 s CABLE, FLEXIBLE FLAT (30 CORE) (SILVER)
608 3-165-162-01 s SCREW(+P2.6X5)(TYPE 1) (ST)
609 3-185-867-01 o CATCHER, MAGNET (FERRITE)
610 3-185-875-01 o HINGE, REAR (WHITE)
3-185-875-11 s HINGE, REAR (BLACK)
611 3-565-714-00 o SHAFT,CHASSIS
612 3-602-483-01 s KNOB,VOLUME 6
613 3-615-750-62 s SHIELD CUSHION(C)
614 3-627-299-01 o CAP,MEMORY STICK (WHITE)
615 3-627-700-03 o SLOT,MEMORY STICK (WHITE)
616 3-627-701-01 o EJECTOR,MEMORY STICK
617 3-627-703-03 o LEAF SPRING
618 3-644-002-00 o CUSHION,HANDLE (RBR)
619 3-673-018-00 s SCREW,BLIND (PLA) (WHITE)
3-673-018-11 s SCREW, BLIND (PLA) (BLACK)
620 3-692-320-01 o BUTTON
621 3-692-321-01 o BUTTON
622 3-692-322-01 o BUTTON
623 3-692-324-01 o BUTTON
624 3-692-325-01 o BUTTON
625 3-694-181-01 s AROCK PRECISION +P2.6X5 TYPE 1
626 3-701-441-11 s WASHER PLASTIC (4.1X0.25)
627 3-719-159-01 s SCREW (M3), (+ BW) (STEEL)
628 3-748-142-01 s COVER,CONNECTOR
629 3-872-577-01 s KNOB,VOLUME DIA.6
630 3-872-699-01 s VR SLEEVE
631 3-872-713-01 s CUSHION,DROP PROTECT REAR
632 3-872-714-01 s CUSHION,DROP PROTECT INCOM
7-623-923-01 s WASHER,POLYETHYLENE 2.6
7-682-251-04 s SCREW +K 3X14
7-682-548-04 s SCREW +B3X8
7-682-903-01 s SCREW +PWH 3X5
7-685-534-14 s SCREW +BTP2.6X8 (SILVER)
7-685-534-19 s SCREW +BTP2.6X8(EP-FE/ZNBK/CM2) (BLACK)
7-688-003-13 s WASHER W3 MIDDLE
*
:
*
: Refer to Section 1-6. “Notes for Replacing Parts” of the Maintenance Manual volume 1.
