1-33
HDC1000/V2 (J, E)
MIC Panel Assembly (HDC1400/1450/1500/1550/1580/1600)
No. Part No. SP Description
1801
!
*
A-1159-984-A s MOUNTED CIRCUIT BOARD, CN-2619G (GOLD) (HDC1400/1450/1500/1550/1580/1600)
!
*
A-1099-119-A s MOUNTED CIRCUIT BOARD, CN-2619 (SILVER) (HDC1500/1550/1600)
1802
!
*
A-1159-985-A s MOUNTED CIRCUIT BOARD, CN-2621G (GOLD) (HDC1500/1550/1580/1600)
*a
!
*
A-1099-121-A s MOUNTED CIRCUIT BOARD, CN-2621 (SILVER) (HDC1500/1550/1600)
*a
!
A-1251-711-A s MOUNTED CIRCUIT BOARD, CN-2621GA (HDC1400/1450/1500/1550/1580/1600)
*b
1803 1-784-240-11 s CONVERTER, COAXIAL CONNECTOR (HDC1500/1550/1600)
1804 1-830-742-11 s CABLE ASSEMBLY, COAXIAL (HDC1500/1550/1600)
1805
*
1-833-557-11 s CABLE, FLEXIBLE FLAT (40 CORE) (GOLD) (HDC1400/1450/1500/1550/1580/1600)
*
1-830-483-11 s CABLE, FLEXIBLE FLAT (40 CORE) (SILVER) (HDC1500/1550/1600)
1806
*
1-831-663-11 s CABLE, FLEXIBLE FLAT (36 CORE) (GOLD) (HDC1400/1450/1500/1550/1580/1600)
*
1-830-752-11 s CABLE, FLEXIBLE FLAT (36 CORE) (SILVER) (HDC1500/1550/1600)
1807 3-729-076-11 s SCREW +B2X4 (STEEL)
1808 3-748-142-01 s COVER,CONNECTOR
1809 3-796-985-02 s CUSHION,DROP PROTECTION
1810 3-796-986-01 s KNOB,SLIDE SW
1811 3-796-993-01 s CUSION DROP PROTEICTION TOGGLE
1812 3-796-995-01 s DROP PROTECTION(SW)
1813 3-796-996-02 s KNOB(A),SW
1814 3-868-657-03 s CAP,BNC
1815 3-872-598-02 s PLATE,MIC PANEL
1816 3-872-935-01 s CAP,BNC
1817 3-903-833-02 s CAP,CONNECTOR
1818 3-965-077-02 s SCREW, SPECIAL (M2)
1819 4-654-273-02 s ACE (M2), LOCK
1820 3-993-496-01 s SHEET2 (TRIAX), PROMPTER (HDC1550)
3-211-442-01 s LABEL, PROMPTER/SDI (HDC1400)
3-285-820-01 s LABEL, PROMPTER/SDI1450
7-627-556-58 s SCREW,PRECISION +P2.6X5
*
:
*
: Refer to Section 1-6. “Notes for Replacing Parts” of the Maintenance Manual volume 1.
*a: Serial No. 10001 through 13159 (HDC1500: SY)
30001 through 33046 (HDC1500: J)
40001 through 40120 (HDC1500: CE)
400001 through 400349 (HDC1500: CE)
10001 through 11018 (HDC1550: UC)
40001 through 40050 (HDC1550: CE)
400001 through 410061 (HDC1550: CE)
50001 through 50070 (HDC1580: CN)
30001 through 33005 (HDC1600: J)
*b: Serial No. 10001 and higher (HDC1400: UC)
30001 and higher (HDC1400: J)
400001 and higher (HDC1400: CE)
50001 and higher (HDC1400: E)
10001 and higher (HDC1450: UC)
400001 and higher (HDC1450: CE)
13160 and higher (HDC1500: SY)
33047 and higher (HDC1500: J)
40121 and higher (HDC1500: CE)
400350 and higher (HDC1500: CE)
50001 and higher (HDC1500: E)
11019 and higher (HDC1550: UC)
40051 and higher (HDC1550: CE)
410062 and higher (HDC1550: CE)
50071 and higher (HDC1580: CN)
33006 and higher (HDC1600: J)
