1-6-4. E : 62 : 12 [Shift Lens Overheating (Yaw)] Occurred
Connect the adjustment remote commander (RM-95 or NEW LANC JIG) and perform the following process.
Order Page Address Data Procedure
10 0101
20 1007
3
D
47 F0 Press PAUSE (Write) button.
(7D)
4
D
49 01 Press PAUSE (Write) button. (Note 1)
(7D)
5
D
49 00 Press PAUSE (Write) button.
(7D)
6
D
47 10 Press PAUSE (Write) button.
(7D)
7
D
49 01 Press PAUSE (Write) button. (Note 1)
(7D)
8
D
49 00 Press PAUSE (Write) button.
(7D)
90 1000
10 0 01 00
11
Check if the shift lens moves while setting the order 3 to 8. If the shift lens does not move, replace the
lens block (Note 2). When the shift lens moved, proceed to the order 12.
12
While setting the order 3 to 8, measure with an oscilloscope the output voltage of R6244 in the periphery of
IC6203 on the YY-003 board to check the output voltage varies.
13
If the output voltage does not vary, replace the lens block (Note 2). When the output voltage varied,
proceed to the order 14.
14 Turn the power OFF.
15
While measuring with an oscilloscope the output voltage of R6233 in the periphery of IC6203 on the
YY-003 board, turn the power ON to check that the output voltage immediately after the power on
change as shown in Fig. 2.
16
If the output voltage change as shown in Fig. 2, replace the lens block (Note 2). If it does not change as
shown in Fig. 2, inspect the camera control circuit (IC4201 of TT-003 board) periphery.
Note 1: Finish this operation within 10 seconds. If it is likely to take more than 10 seconds, set page: D (7D), address: 49, data:
00, and then retry.
Note 2: When the lens block was replaced, execute a necessary adjustment items referring to Service Manual, ADJ.
After the adjustment, make sure with the STEADYSHOT turned ON that the steadyshot functions appropriately in the
handheld operation.
