Sony HDR-FX7 - Overall Section-1 Exploded View

5-2
5. REPAIR PARTS LIST
5. REPAIR PARTS LIST
HDR-FX7/FX7E_L2
DISASSEMBLY
HARDWARE LIST
Ref. No. Part No. Description Ref. No. Part No. Description
1 2-891-978-01 CABINET, TOP #49 2-630-005-31 SCREW (M2), NEW TRUSTER, P2 (Black)
5-1-1. OVERALL SECTION-1
5-1. EXPLODED VIEWS
Cabinet (L) Section
(See Page 5-9)
Handle Section
(See Page 5-11)
Overall Section-2
(See Page 5-3)
1
#49
#49
#49
#49
#49
#49
#49
