5-17
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
HDR-FX7/FX7E_L2
A-1223-596-A PRISM ASSY (SERVICE)
(Not supplied) EE-006 BOARD, COMPLETE
**********************
(EE-006 complete board and IC5601 are not supplied,
but they are included in prism assy.)
< CAPACITOR >
C5601 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5602 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5603 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5604 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5605 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5606 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5607 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5608 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5609 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5610 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5611 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5612 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
C5613 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5614 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5615 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5616 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5617 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5618 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5619 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5620 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5621 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5622 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5623 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5624 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C5625 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5626 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5627 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5628 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5629 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5630 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5631 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5632 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5633 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5634 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5635 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5636 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5637 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C5638 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
< CONNECTOR >
* CN5601 1-820-806-21 CONNECTOR, COAXIAL (RECEPTACLE)
< FERRITE BEAD >
FB5601 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB5602 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB5603 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
IC5601 (Not supplied) IMX013BLA-13 (CMOS IMAGER) (Note)
EE-006 FP-031 FP-032 FP-228 FP-481
< COIL >
L5601 1-400-588-11 INDUCTOR 10uH
L5602 1-400-588-11 INDUCTOR 10uH
L5603 1-400-588-11 INDUCTOR 10uH
L5604 1-400-588-11 INDUCTOR 10uH
< RESISTOR >
R5601 1-218-953-11 RES-CHIP 1K 5% 1/16W
R5609 1-218-941-81 RES-CHIP 100 5% 1/16W
(Not supplied) FP-031 FLEXIBLE BOARD
********************
(This flexible board is included in MD (N100) sub assy A (A-1080-997-A).)
< DIODE >
D902 6-500-652-01 DIODE GL453SE0000F (TAPE LED)
< HOLE ELEMENT >
H901 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (S REEL)
H902 8-719-067-74 ELEMENT, HOLE HW-105A-CDE-T (T REEL)
< CONNECTOR >
MIC903 1-818-576-11 PIN, CONNECTOR (WITH DETECTION)
< TRANSISTOR >
Q901 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE END)
Q902 6-550-672-01 TRANSISTOR PT4850FJE00F (TAPE TOP)
< SWITCH >
S901 1-786-448-22 SWITCH, PUSH (1 KEY) (CC DOWN)
(Not supplied) FP-032 FLEXIBLE BOARD
********************
(This flexible board with S903 is included in MD (N100) sub assy A
(A-1080-997-A).)
1-677-049-11 FP-228 FLEXIBLE BOARD (DEW SENSOR)
********************
A-1217-226-A FP-481 FLEXIBLE BOARD, COMPLETE
******************************
< CAPACITOR >
C101 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< DIODE >
D101 8-719-064-07 DIODE SML-310LTT86 (REC LAMP (FRONT))
D102 8-719-073-01 DIODE MA111-(K8).S0
< IC >
IC101 6-600-163-01 IC RS-770
Note: イメージャの交換時は4-4ページのイメージャ
交換時の注意を必ずお読みください。
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-3 when changing the imager.
To Next Page
