HDR-FX7/FX7E_L2
< RESISTOR >
R101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R102 1-216-805-11 METAL CHIP 47 5% 1/10W
A-1217-227-A FP-482 FLEXIBLE BOARD, COMPLETE
*******************************
< FERRITE BEAD >
FB201 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB202 1-414-760-21 FERRITE, EMI (SMD) (1608)
< JACK >
J201 1-794-525-12 JACK, MIC (MIC (PLUG IN POWER))
A-1217-228-A FP-483 FLEXIBLE BOARD, COMPLETE
*******************************
< RESISTOR >
R301 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R302 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
< SWITCH >
S303 1-771-487-21 SWITCH, SLIDE (HANDLE ZOOM (H/L/OFF))
A-1217-229-A FP-484 FLEXIBLE BOARD, COMPLETE
*******************************
< CAPACITOR >
C4001 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN4001 1-817-543-51 CONNECTOR, FPC (ZIF) 27P
< DIODE >
D4001 8-719-073-01 DIODE MA111-(K8).S0
D4002 8-719-064-07 DIODE SML-310LTT86 (REC LAMP (BACK))
< IC >
IC4001 6-600-163-01 IC RS-770
< RESISTOR >
R001 1-216-805-11 METAL CHIP 47 5% 1/10W
R002 1-216-821-11 METAL CHIP 1K 5% 1/10W
A-1217-230-A FP-485 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
* CN501 1-816-643-51 FFC/FPC CONNECTOR (LIF) 10P
* CN502 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< RESISTOR >
R501 1-216-295-91 SHORT CHIP 0
< SWITCH >
S001 1-786-180-31 SWITCH, PUSH (1KEY) (EJECT)
A-1217-231-A FP-486 FLEXIBLE BOARD, COMPLETE
*******************************
< FERRITE BEAD >
FB601 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB602 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB603 1-414-760-21 FERRITE, EMI (SMD) (1608)
< JACK >
J601 1-794-525-12 JACK, MIC (i (HEADPHONES))
< RESISTOR >
R602 1-216-295-91 SHORT CHIP 0
R603 1-216-864-11 SHORT CHIP 0
A-1217-232-A FP-487 FLEXIBLE BOARD, COMPLETE
*******************************
< SWITCH >
S701 1-771-039-31 SWITCH, PUSH (PANEL REVERSE)
S702 1-786-148-11 SWITCH, PUSH (1 KEY) (PANEL OPEN/CLOSE)
Electrical parts list of the GG-003 and HH-
003 boards are not shown.
Pages 5-19 and 5-20 are not shown.
FP-481 FP-482 FP-483 FP-484 FP-485 FP-486 FP-487
