5-21
Ref. No. Part No. Description Ref. No. Part No. Description
HDR-FX7/FX7E_L2
A-1217-208-A II-003 BOARD, COMPLETE
*********************
< CONNECTOR >
CN9201 1-817-544-51 CONNECTOR, FPC (ZIF) 39P
* CN9202 1-794-276-21 CONNECTOR, SQUARE TYPE 4P (HDV/DV)
CN9203 1-815-794-13 CONNECTOR (MULTIPLE) (A/V OUT)
CN9204 1-818-607-12 CONNECTOR, SQUARE TYPE 10P
(COMPONENT OUT)
< DIODE >
D9201 6-500-252-01 DIODE SML-512WWT86 (CHARGE)
D9203 8-719-056-85 DIODE UDZ-TE-17-8.2B
D9204 8-719-056-85 DIODE UDZ-TE-17-8.2B
D9205 8-719-056-85 DIODE UDZ-TE-17-8.2B
D9206 6-500-750-01 DIODE NSAD500H-T1-A
< FERRITE BEAD >
FB9201 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB9202 1-414-760-21 FERRITE, EMI (SMD) (1608)
< THERMISTOR >
TH9201 1-805-726-11 THERMISTOR, POSITIVE
TH9202 1-805-726-11 THERMISTOR, POSITIVE
TH9203 1-805-726-11 THERMISTOR, POSITIVE
TH9204 1-805-726-11 THERMISTOR, POSITIVE
< VARISTOR >
VDR921 1-803-974-21 VARISTOR, CHIP (1608)
VDR922 1-803-974-21 VARISTOR, CHIP (1608)
VDR924 1-803-974-21 VARISTOR, CHIP (1608)
A-1227-577-A JJ-004 BOARD, COMPLETE (SERVICE)
**********************
< CAPACITOR >
C8001 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C8002 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C8005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8006 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8007 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8008 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8009 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8010 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C8011 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C8012 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C8013 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C8014 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C8017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8018 1-127-895-91 TANTAL. CHIP 22uF 20% 4V
< CONNECTOR >
* CN8001 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< IC >
IC8001 8-759-489-19 IC uPC6756GR-8JG-E2
< RESISTOR >
R8001 1-218-969-11 RES-CHIP 22K 5% 1/16W
R8002 1-218-969-11 RES-CHIP 22K 5% 1/16W
R8003 1-218-969-11 RES-CHIP 22K 5% 1/16W
R8004 1-218-969-11 RES-CHIP 22K 5% 1/16W
R8005 1-218-989-11 RES-CHIP 1M 5% 1/16W
R8007 1-218-965-11 RES-CHIP 10K 5% 1/16W
R8008 1-218-965-11 RES-CHIP 10K 5% 1/16W
R8009 1-218-989-11 RES-CHIP 1M 5% 1/16W
< SENSOR >
* SE8001 1-479-022-51 SENSOR, ANGULAR VELOCITY (PITCH)
* SE8002 1-479-022-61 SENSOR, ANGULAR VELOCITY (YAW)
A-1217-210-A MM-061 BOARD, COMPLETE
************************
1-870-215-11 MM-061 BOARD
< CAPACITOR >
C8301 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C8302 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8303 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C8304 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C8305 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C8306 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C8307 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8308 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8309 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8310 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C8311 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C8312 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C8313 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C8314 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C8315 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C8316 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C8317 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C8320 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C8321 1-100-611-91 CERAMIC CHIP 22uF 20% 6.3V
C8322 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8323 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C8324 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8325 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8326 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C8327 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
CN8301 1-778-507-21 PIN, CONNECTOR (PC BOARD) 4P
CN8302 1-778-507-21 PIN, CONNECTOR (PC BOARD) 4P
* CN8303 1-819-873-51 CONNECTOR, FPC (ZIF) 21P
* CN8304 1-816-654-51 FFC/FPC CONNECTOR (LIF) 6P
< IC >
IC8301 6-707-702-01 IC NJM2746RB1 (TE2)
IC8302 6-707-702-01 IC NJM2746RB1 (TE2)
IC8303 6-707-702-01 IC NJM2746RB1 (TE2)
IC8304 6-707-702-01 IC NJM2746RB1 (TE2)
II-003 JJ-004 MM-061
