Sony HDR-FX7 - Mounted Parts Location - EE-006 Board

4-65
4-3. PRINTED WIRING BOARDS
HDR-FX7/FX7E_L2
EE-006
no mark : side A
*
mark : side B
4-4. MOUNTED PARTS LOCATION
EE-006 BOARD
C5601 A-1
C5602 B-1
C5603 A-1
C5604 B-1
C5605 B-2
C5606 A-2
C5607 B-2
C5608 A-2
C5609 A-1
C5610 A-1
C5611 A-1
C5612 A-1
C5613 B-1
C5614 B-2
C5615 B-1
C5616 A-2
C5617 B-1
C5618 A-2
C5619 A-1
C5620 A-1
C5621 A-1
C5622 A-1
C5623 A-1
C5624 A-1
C5625 B-1
C5626 B-1
C5627 B-2
C5628 A-2
C5629 A-1
C5630 A-1
C5631 A-1
C5632 A-1
C5633 B-2
C5634 A-2
C5635 A-1
C5636 A-1
C5637 B-2
C5638 A-2
CN5601 A-2
FB5601 A-1
FB5602 A-1
FB5603 B-1
IC5601 B-1
L5601 A-1
L5602 A-1
L5603 B-2
L5604 A-2
R5601 B-2
R5609 B-1
