Sony HDR-FX7 - Overall Disassembly Section 3

2-4
HDR-FX7/FX7E_L2
2-1-3. OVERALL SECTION-3
Follow the disassembly in the numerical order given.
1 BT Block (1-1 to 1-9)
2 OO-003 Board (2-1 to 2-2)
3 TT-003 Board (3-1 to 3-14)
EXPLODED VIEW
HARDWARE LIST
1 BT Block
2 OO-003 Board
3TT-003
Board
1-2 (#50)
1-3
(Claw)
1-9 (#49)
1-7 (#49)
1-8
1-5
1-4
1-1
1-6
3-12 (#50)
3-6
3-1
3-4
(#50)
3-7
3-14
2-2 (#50)
2-1
YY-
003
3-5
(#53)
3-3
3-2
3-8
(Note)
3-9
(Note)
3-10
(Note)
3-11
3-13
(Claw)
Note: Refer to page 2-1 “Note
for disconnecting the
harness (coaxial cable)”.
