HDR-SR1/SR1E_L2
FP-478 FLEXIBLE BOARD
(PANEL REVERSE DETECT)
PD-291 BOARD (LCD DRIVE)
FP-463 FLEXIBLE BOARD
FP-475 FLEXIBLE BOARD
(PANEL OPEN/CLOSE)
BL-003 BOARD (EVF, EVF BACKLIGHT)
CK-164 BOARD (CONTROL SWITCH)
CONTROL SWITCH BLOCK (SB20100)
FP-471 FLEXIBLE BOARD
(DC IN, BATTERY TERMINAL)
FP-431 FLEXIBLE BOARD
(MD-HDD CONNECTION)
FP-523 FLEXIBLE BOARD (JACK)
FP-465 FLEXIBLE BOARD
FR-256 BOARD
(REMOTE COMMANDER RECEIVER)
FP-462 FLEXIBLE BOARD
MS-328 BOARD (USB/MS CONNECTOR)
FP-480 FLEXIBLE BOARD
JK-313 BOARD
(AV/COMPONENT CONNECTOR)
FP-464 FLEXIBLE BOARD
FP-469 FLEXIBLE BOARD
(CONTROL SWITCH)
FP-477 FLEXIBLE BOARD
(CHARGING CAPACITOR)
STROBE FLASH UNIT (FL20000)
CONTROL SWITCH BLOCK (PS20100)
MOTOR UNIT (LENS BARRIER)
FP-473 FLEXIBLE BOARD
(HDMI CONNECTOR)
FP-460 FLEXIBLE BOARD (HOT SHOE)
FP-461 FLEXIBLE BOARD (MIC)
FP-470 FLEXIBLE BOARD (MIC JACK)
FP-522 FLEXIBLE BOARD
CONTROL SWITCH BLOCK (MF20000)
Link
Link
4-2. SCHEMATIC DIAGRAMS
COMMON NOTE FOR SCHEMATIC DIAGRAMS
