Sony HT-FS1 - Page 41

41
GB
Additional Information
Formats supported by this
system
Digital input formats supported by this system
are as follows.
* Linear PCM accepts sampling frequencies of no
more than 48 kHz.
Amplifier section
Power output (rated)
Front L / Front R: 40 W + 40 W
(at 8 ohms, 1 kHz, 1 %
THD)
RMS output power (reference)
Front L / Front R: 50 W + 50 W
(at 8 ohms, 1 kHz, 10 %
THD)
Subwoofer: 100 W (at 4 ohms, 100 Hz,
10 % THD)
Inputs (Analog)
TV Impedance: 30 kohms
Inputs (Digital)
TV, DVD Optical
SAT Coaxial, optical
HDMI section
Connector HDMI 19pin-standard
connector
Video inputs/outputs BD, DVD, SAT:
640 × 480p@60 Hz
720 × 480p@59.94/60 Hz
1440 × 480p@59.94/60 Hz
(pixel sent 2 times)
1280 × 720p@59.94/60 Hz
1920 × 1080i@59.94/
60 Hz
1920 × 1080p@59.94/
60 Hz
720 × 576p@50 Hz
1440 × 576p@50 Hz
(pixel sent 2 times)
1280 × 720p@50 Hz
1920 × 1080i@50 Hz
1920 × 1080p@50 Hz
1920 × 1080p@24 Hz
Audio inputs BD, DVD, SAT: Linear
PCM 7.1ch/
Dolby Digital/DTS
Speakers (SS-FS1)
Speaker system 2-Way speaker system,
Bass reflex,
Magnetically Shielded
Speaker unit Woofer: 65 mm cone type
Tweeter: 40 mm cone type
Rated impedance 8 ohms
Dimensions (approx.) 95 mm × 185 mm × 80 mm
(w/h/d)
95 mm × 215 mm × 105
mm (w/h/d) with stand
Mass (approx.) 0.85 kg
0.9 kg with stand
Active subwoofer (SA-FS1)
Speaker system Subwoofer system,
Bass reflex
Speaker unit 160 mm cone type
Dimensions (approx.) 160 mm × 500 mm × 360
mm (w/h/d)
Mass (approx.) 10 kg
Power requirements 220 – 240 V AC, 50/60 Hz
Power consumption
On: 55 W
Active Standby (Control for HDMI is on):
Signal in: 5 W (maximum)
No signal: 1.5 W (minimum)
Standby (Control for HDMI is off): 0.3 W
Specifications
Format Supported/Not supported
Dolby Digital a
DTS a
Linear PCM (2ch)* a
Linear PCM (5.1ch,
7.1ch)* (Only on
HDMI)
a
Dolby Digital Plus ×
Dolby True HD ×
DTS-HD ×
continued
