Self-diagnosis Code
Symptom/State Correction
E 6 1 3 0 Reset position detection error on the
stepper iris initializing
Turn the power on to open lens barrier. Disconnect the bat-
tery or power cord, and then connect again. And confirm
that the iris blades in lens are working.
If iris blades do not work, check the iris motor drive circuit
in lens drive block. If iris blades work normally, confirm
that they are closing completely and confirm following
items.
• Case of the iris blades do not close normally. Replace
the lens block.
• Case of “E: 61: 30” is appeared and iris blades closed
completely. Confirm that communication with lens
block is normal.
• Case of LCD is not displayed normally, check that
connection between imager board and main board.
• Case of LCD is displayed normally, replace the lens
block.
E 6 1 3 1 Error in detection of the Reset Posi-
tion at the time of Stepper IR Filter
initialization
Check the signal line connection between the lens block and
the lens control circuit.
Check whether this error is due to the lens or the board.
Replace the faulty lens or board.
E 6 1
4 0
*1
CMR initialization error Turn power off and turn power on again.
E 6 1
4 1
*1
Connection error between CMR
control IC and CPU.
Turn power off and turn power on again.
E 6 1
4 2
*1
Error of thermistor (CMR) Turn power off and turn power on again.
E 6 1
4 3
*1
Abnormality of steadyshot IC
(CMR)
Turn power off and turn power on again.
E 6 1
4 4
*1
Position detection error of the CMR
filter.
Turn power off and turn power on again.
E 6 2 0 0 Steadyshot does not work well.
(With PITCH angular velocity sen-
sor output stopped)
The peripheral circuit of the PITCH angular velocity sensor
may be faulty.
Replace the board that contains this peripheral circuit.
E 6 2 0 1 Steadyshot does not work well.
(With YAW angular velocity sensor
output stopped)
The peripheral circuit of the YAW angular velocity sensor
may be faulty.
Replace the board that contains this peripheral circuit.
E 6 2 0 2 Abnormality of IC for steadyshot. Check signal line connections from CPU through steady-
shot IC to PITCH/YAW drive.
When there is no problem with the connections, replace the
board that contains this peripheral circuit.
E 6 2 0 3 Communication error of steadyshot
IC and CPU
The steadyshot circuit may be faulty.
Replace the board that contains this peripheral circuit.
E 6 2 0 4 Image vibration correction during
steadyshot does not work.
The image vibration angular velocity sensor (ROLL SEN-
SOR) peripheral circuit may be faulty.
Replace the board that contains this peripheral circuit.
E 6 2 1 0 Shift lens initializing failure
Replacement of lens block.
*2
If an error occurs again, steadyshot circuit may be faulty.
Replace the board that contains this peripheral circuit.
E 6 2 1 1 Shift lens overheating (PITCH) Check signal line connections from CPU through steady-
shot IC to PITCH/YAW drive.
When there is no problem with the connections, check
whether this error is due to the lens or the board. Replace
the faulty lens or board.
Continued
*1: Function of this code is not provided in this unit.
*2: When the lens block was replaced, start the Adjust Manual in the Adjust Station and execute the necessary adjustment items. After
the adjustment, make sure with the STEADYSHOT turned ON that the steadyshot functions appropriately in the handheld operation.
HXR-NX80/HXR-MC88
2-3
To Next Page
