Examples of four timer programs
AM 7:00 7:30
fr
ON OFF
9:00 9:15
e2) Fo
ON, |OFF
t !
8:30 | | 9:30
PT3 ON ee OF
The station preset on the PT2
8:00 8:15 key will be received.
PT4 ool
ON OFF
e@The stations will be received in the order of the preset turn-on
times. ((PT1] = [PT4] => [PT3] = [PT2] in the above example.)
@When two programs overlap, priority is given in the order from
PT1 key to PT4 key. In the above example, the station preset on
the PT2 key will be received from 9:00 to 9:15 and the station
preset on PT3 key will return from 9:15 to 9:30.
To use the sleep timer after setting the timer programs
Press the SLEEP key and tune in the desired station.
You can fall asleep listening to the radio and woken up by the other
program.
@The programmable timer has priority over the sleep timer. So, if
the turn-on time of the programmable timer comes during the sleep
timer operation, the station preset on the PT key will be received.
Error indication
During programmable timer operation, none of the keys on the
front panel except the LIGHT key and the BATTERY CHECK key
nor the MANUAL TUNING/TIME ADJ knob function. When you
touch a key or the knob, this indication will appear for approx. 5
seconds and will then disappear. To operate the keys or the
knob, set the POWER switch to ON.
\
SAAS AY
EXTERNAL ANTENNA CONNECTION
(Only for models with the external antenna jacks provided)
FOR FM/AIR BAND RECEPTION
In
a
steel-frame
building,
a
mountainous
area,
at
a
distance
from
the
transmitter
or
in
a
location
where
ignition
noise
is
severe,
FM/
AIR
band
reception
may
be
unsatisfactory
with
the
telescopic
antenna.
In
this
case,
connect
the
optional
Sony
AN-3
VHF
antenna
or
other
appropriate
external
antenna.
Connection
See illustration [H) on page 5.
1
Connect
the
50-75
ohm
coaxial
cable
to
the
supplied
antenna
connector.
@ Fold the tabs on the antenna connector.
@ Prepare the end of the cable as illustrated.
@)
Fix
the
center
conductor
and
shield
braid
as
illustrated.
@Close the lid and tighten the screws.
2 Connect the antenna connector to the EXT ANT AIR/FM jack of
the receiver.
Notes
@
Locate
an
outdoor
antenna
as
far
away
from
the
street
as
possi-
ble.
@For further details, refer to the antenna instruction manual.
FOR SW RECEPTION
Usually,
the
telescopic
antenna
is
sufficient
for
SW
reception.
However,
in
a
building
or
for
more
stable
SW
reception,
the
use
of
the
supplied
SW
external
antenna
is
recommended.
Connection
See illustration [1] on page 5. ;
1 Connect the ground wire (if necessary) and the spade lug of the
SW external antenna to the terminals on the supplied antenna
connector, close the lid and tighten the screws.
2 Connect the antenna connector to the EXT ANT AM jack of the
receiver,
When reception is noisy, connect one end of a ground wire to the
antenna connector as illustrated and the other end directly to a
convenient earth ground.
Notes :
@ When an external antenna is connected to the EXT ANT AM jack,
the built-in ferrite bar antenna does not function.
@ Never connect a ground wire to a gas pipe. Doing so could cause
a fire.
@When there is lightning and you are using an external antenna,
immediately disconnect the ac power adaptor (if connected) from
the wall outlet. Never touch the antenna wire during a lightning
storm.
FOR MWI/LW RECEPTION
Use an optional AN-1 wide range antenna for better reception.
Connection
See illustration [J] on page 5.
Connect the OUTPUT of the antenna controller * and the INPUT of
the antenna coupler* with the RK-69A connecting cord* or con-
nect the OUTPUT of the antenna controller and the EXT ANT of the
ICF-2001 D/2010 with the connecting cord.
* supplied with the AN-1 wide range antenna.
