14
ICF-CD855V
Adjustment and Connecting Location:
T2
FM/TV/WEATHER
IF Adjustment
T1
AM IF Adjustment
L6
AM VCO Voltage Adjustment
L2
FM/TV (2 – 6 CH)
Tracking Adjustment
CT2
L1
AM Tracking Adjustment
L3
CT4
L4
CT3
L5
CT5
TV (7 – 13 CH)/
WEATHER
Tracking Adjustment
TV (7 – 13 CH)/
WEATHER
VCO Voltage Adjustment
FM/TV (2 – 6 CH)
VCO Voltage Adjustment
– TUNER BOARD (Component Side) –
– TUNER BOARD (Conductor Side) –
TP
(GND)
TP
(VT)
TP
(ANT)
CNP304
1
4
– MAIN BOARD (Conductor Side) –
