Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
44
ICF-CD855V
KEY-B LCD MAIN
R634 1-216-841-11 METAL CHIP 47K 5% 1/10W
R635 1-216-841-11 METAL CHIP 47K 5% 1/10W
R636 1-216-821-11 METAL CHIP 1K 5% 1/10W
R638 1-216-821-11 METAL CHIP 1K 5% 1/10W
R640 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S607 1-786-097-21 SWITCH, TACT (TUNE/TIME SET +, >)
S608 1-786-097-21 SWITCH, TACT (RADIO ON, BAND)
S609 1-786-097-21 SWITCH, TACT (CD u)
S610 1-786-097-21 SWITCH, TACT (SLEEP)
S611 1-786-097-21 SWITCH, TACT (NAP)
S612 1-786-097-21 SWITCH, TACT (ALARM B)
S613 1-786-097-21 SWITCH, TACT (TUNE/TIME SET –, .)
S614 1-786-097-21 SWITCH, TACT (OFF x, ALARM RESET)
************************************************************
* A-4542-935-A LCD BOARD, COMPLETE
********************
< CAPACITOR >
C607 1-115-156-11 CERAMIC CHIP 1uF 10V
C610 1-115-156-11 CERAMIC CHIP 1uF 10V
C618 1-115-156-11 CERAMIC CHIP 1uF 10V
C619 1-115-156-11 CERAMIC CHIP 1uF 10V
< CONNECTOR >
CNP606 1-779-555-21 CONNECTOR, FFC (LIF (NON-ZIF)) 18P
CNP607 1-779-555-21 CONNECTOR, FFC (LIF (NON-ZIF)) 18P
< LED >
D609 6-500-915-01 LED SLP-WH118A-51-SW (LCD BACK LIGHT)
D610 6-500-915-01 LED SLP-WH118A-51-SW (LCD BACK LIGHT)
< SHORT >
JC605 1-216-864-11 SHORT CHIP 0
< LIQUID CRYSTAL DISPLAY >
LCD601 1-805-525-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q609 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q610 8-729-028-83 TRANSISTOR DTA124EUA-T106
Q611 8-729-028-73 TRANSISTOR DTA114EUA-T106
Q612 8-729-028-83 TRANSISTOR DTA124EUA-T106
< RESISTOR >
R655 1-216-817-11 METAL CHIP 470 5% 1/10W
R656 1-216-821-11 METAL CHIP 1K 5% 1/10W
R658 1-216-821-11 METAL CHIP 1K 5% 1/10W
R660 1-216-809-11 METAL CHIP 100 5% 1/10W
R661 1-216-817-11 METAL CHIP 470 5% 1/10W
R662 1-216-821-11 METAL CHIP 1K 5% 1/10W
R664 1-216-821-11 METAL CHIP 1K 5% 1/10W
R666 1-216-809-11 METAL CHIP 100 5% 1/10W
************************************************************
* A-4542-928-A MAIN BOARD, COMPLETE
*********************
3-253-143-01 SCREW (B2.6), (+) P TAPPING
< CAPACITOR >
C101 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C102 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C109 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C110 1-126-947-11 ELECT 47uF 20% 35V
C111 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C112 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C114 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C115 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C117 1-126-916-11 ELECT 1000uF 20% 6.3V
C118 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C119 1-128-551-11 ELECT 22uF 20% 63V
C120 1-126-963-11 ELECT 4.7uF 20% 50V
C121 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C201 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C202 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C206 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C207 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C209 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C210 1-126-947-11 ELECT 47uF 20% 35V
C211 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C212 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C214 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C215 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C217 1-126-916-11 ELECT 1000uF 20% 6.3V
C218 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C219 1-128-551-11 ELECT 22uF 20% 63V
C220 1-126-963-11 ELECT 4.7uF 20% 50V
C221 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C302 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C304 1-104-665-11 ELECT 100uF 20% 25V
C309 1-135-834-11 CERAMIC CHIP 2.2UF 6.3V
C310 1-135-834-11 CERAMIC CHIP 2.2UF 6.3V
C311 1-126-947-11 ELECT 47uF 20% 35V
C312 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C315 1-126-947-11 ELECT 47uF 20% 35V
C316 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C317 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C318 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C319 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C320 1-126-963-11 ELECT 4.7uF 20% 50V
C322 1-104-665-11 ELECT 100uF 20% 25V
C323 1-126-963-11 ELECT 4.7uF 20% 50V
C324 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C325 1-126-963-11 ELECT 4.7uF 20% 50V
