Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
47
ICF-CD855V
R913 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R914 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R915 1-216-809-11 METAL CHIP 100 5% 1/10W
R916 1-216-821-11 METAL CHIP 1K 5% 1/10W
R917 1-216-821-11 METAL CHIP 1K 5% 1/10W
R918 1-216-833-11 METAL CHIP 10K 5% 1/10W
R919 1-216-833-11 METAL CHIP 10K 5% 1/10W
< SWITCH >
S401 1-570-853-11 SWITCH, SLIDE (BRIGHTNESS)
S403 1-771-349-21 SWITCH, TACT (CLOCK)
< VIBRATOR >
X401 1-760-252-12 VIBRATOR, CRYSTAL (32.768kHz)
X402 1-795-054-21 VIBRATOR, CERAMIC (4.19MHz)
************************************************************
RELAY BOARD
************
< CONNECTOR >
CNP704 1-784-742-11 CONNECTOR, FFC 20P
CNP705 1-779-553-21 CONNECTOR, FFC (LIF (NON-ZIF)) 16P
* CNP706 1-566-761-11 PIN, CONNECTOR (PC BOARD) 6P
************************************************************
* A-4542-931-A SIDE BOARD, COMPLETE
********************
< RESISTOR >
R648 1-216-845-11 METAL CHIP 100K 5% 1/10W
R649 1-216-837-11 METAL CHIP 22K 5% 1/10W
R650 1-216-841-11 METAL CHIP 47K 5% 1/10W
R651 1-216-837-11 METAL CHIP 22K 5% 1/10W
R652 1-216-837-11 METAL CHIP 22K 5% 1/10W
R653 1-216-841-11 METAL CHIP 47K 5% 1/10W
R654 1-216-809-11 METAL CHIP 100 5% 1/10W
R667 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S616 1-771-349-21 SWITCH, TACT (MODE)
S617 1-771-349-21 SWITCH, TACT (VOL –)
S618 1-771-349-21 SWITCH, TACT (VOL +)
************************************************************
* A-4542-922-A SNOOZE BOARD, COMPLETE
***********************
< RESISTOR >
R646 1-216-845-11 METAL CHIP 100K 5% 1/10W
R647 1-216-849-11 METAL CHIP 220K 5% 1/10W
< SWITCH >
S615 1-762-196-21 SWITCH, TACT (SNOOZE, SLEEP OFF)
************************************************************
SWITCH BOARD
*************
< SWITCH >
S619 1-571-936-11 SWITCH, LEAF (CD LID OPEN/CLOSE DETECT)
************************************************************
* A-3683-339-A TUNER BOARD, COMPLETE (WHITE)
* A-4547-329-A TUNER BOARD, COMPLETE (SILVER)
**********************
< BAND PASS FILTER >
BPF1 1-781-765-11 FILTER, BAND PASS
< CAPACITOR >
C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3 1-115-871-11 ELECT 1uF 20% 50V
C4 1-126-176-11 ELECT 220uF 20% 10V
C5 1-126-794-11 ELECT 4.7uF 20% 50V
C6 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C7 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V
C9 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C10 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C11 1-162-911-11 CERAMIC CHIP 6PF 0.5PF 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C15 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C19 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C20 1-128-801-11 CERAMIC 22PF 5% 50V
C21 1-128-817-51 CERAMIC 470PF 5% 50V
C22 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C23 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C24 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C25 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C26 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C27 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C28 1-161-051-00 CERAMIC 0.01uF 10% 25V
C29 1-102-508-91 CERAMIC 10PF 0.5PF 50V
C30 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C31 1-102-978-00 CERAMIC 220PF 5% 50V
C32 1-164-361-11 CERAMIC CHIP 0.047uF 25V
C33 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C34 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C35 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C36 1-115-871-11 ELECT 1uF 20% 50V
C37 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C39 1-115-871-11 ELECT 1uF 20% 50V
C40 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C41 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C42 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C43 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C51 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C52 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C53 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C54 1-162-974-11 CERAMIC CHIP 0.01uF 50V
MAIN RELAY SIDE SNOOZE SWITCH TUNER
