Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 15 —
< FILTER >
CF1 1-577-317-11 FILTER, CERAMIC
CF2 1-760-238-71 FILTER, CERAMIC
CF3 1-760-238-71 FILTER, CERAMIC
< TRIMMER >
CT2 1-141-411-11 CAP, ADJ 20PF
CT3 1-141-411-11 CAP, ADJ 20PF
CT1 1-141-550-11 CAP, VAR (INCLUDING CV1) (JE)
CT1 1-151-636-11 CAP, VAR (INCLUDING CV1)
(US,CND,AEP,IT,E,CH,EA)
< VARIABLE CAPACITOR >
CV1 1-141-550-11 CAP, VAR (JE)
CV1 1-151-636-11 CAP, VAR (US,CND,AEP,IT,E,CH,EA)
< DIODE >
D1 8-719-800-76 DIODE 1SS226
D2 8-719-812-41 DIODE GL3PR8 (TUNE)
D3 8-719-921-22 DIODE 1SS277
< IC >
IC1 8-752-062-48 IC CXA1238M-T6
IC2 8-752-064-80 IC CXA1522M
< JACK >
J1 1-566-891-11 JACK (HEADPHONE)
J2 1-764-799-11 JACK, EXTERNAL POWER (DC IN 3V)
< JUMPER RESISTOR >
JR1 1-216-296-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR4 1-216-295-91 SHORT 0
JR6 1-216-295-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-296-91 SHORT 0
JR9 1-216-296-91 SHORT 0
JR10 1-216-296-91 SHORT 0
JR12 1-216-295-91 SHORT 0
JR14 1-216-295-91 SHORT 0
JR20 1-216-295-91 SHORT 0
JR21 1-216-295-91 SHORT 0
JR22 1-216-295-91 SHORT 0
< COIL >
L1 1-501-683-11 ANTENNA, FERRITE-ROD (LW/MW)
L2 1-501-683-11 ANTENNA, FERRITE-ROD (LW/MW)
L3 1-414-142-61 INDUCTOR 1uH
L4 1-406-028-00 COIL, OSC (MW)
L5 1-416-749-11 COIL (LW OSC)
L6 1-428-768-11 COIL, AIR-CORE (US,CND,AEP,IT,E,CH,EA)
L6 1-428-840-11 COIL, AIR-CORE (JE)
L7 1-406-042-00 COIL, FM OSC (US,CND,AEP,IT,E,CH,EA)
* L7 1-422-202-11 COIL (AIR-CORE) (JE)
L8 1-408-592-11 INDUCTOR 1.2uH
L9 1-408-594-21 INDUCTOR 1.8uH
L10 1-408-596-31 INDUCTOR 2.7uH
L11 1-408-597-31 INDUCTOR 3.3uH
L12 1-408-599-31 INDUCTOR 4.7uH
L13 1-408-601-31 INDUCTOR 6.8uH
L14 1-408-410-00 INDUCTOR 12uH
L15 1-408-412-00 INDUCTOR 18uH
L16 1-408-608-31 INDUCTOR 27uH (US,CND,AEP,IT,E,CH,EA)
L16 1-408-611-31 INDUCTOR 47uH (JE)
L17 1-409-895-11 COIL (OSC)
L18 1-409-515-11 COIL (OSC)
L19 1-409-514-11 COIL (OSC)
L20 1-409-513-11 COIL (OSC)
L21 1-409-512-11 COIL (OSC)
L22 1-409-511-11 COIL (OSC)
L23 1-409-510-11 COIL (OSC)
L24 1-409-509-11 COIL (OSC)
L25 1-409-508-11 COIL (OSC) (US,CND,AEP,IT,E,CH,EA)
L25 1-411-856-11 COIL (OSC) (JE)
L26 1-414-142-61 INDUCTOR 1uH
L27 1-414-167-11 INDUCTOR 1mH
L28 1-414-167-11 INDUCTOR 1mH
L29 1-428-769-11 COIL, AIR-CORE
< TRANSISTOR >
Q4 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q5 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q6 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R1 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2 1-216-115-00 METAL CHIP 560K 5% 1/10W
R3 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R4 1-216-073-00 METAL CHIP 10K 5% 1/10W
R7 1-216-025-91 RES,CHIP 100 5% 1/10W
R8 1-216-073-00 METAL CHIP 10K 5% 1/10W
R9 1-216-105-91 RES,CHIP 220K 5% 1/10W
R10 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R12 1-216-049-91 RES,CHIP 1K 5% 1/10W
R13 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R14 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R15 1-216-105-91 RES,CHIP 220K 5% 1/10W
R16 1-247-883-00 CARBON 150K 5% 1/4W
(US,CND,AEP,IT,E,CH,EA)
R17 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R20 1-216-105-91 RES,CHIP 220K 5% 1/10W
R21 1-216-089-91 RES,CHIP 47K 5% 1/10W
R22 1-216-073-00 METAL CHIP 10K 5% 1/10W
R23 1-216-198-91 RES,CHIP 1K 5% 1/8W
R24 1-216-198-91 RES,CHIP 1K 5% 1/8W
R25 1-216-206-00 RES,CHIP 2.2K 5% 1/8W
R26 1-216-174-00 RES,CHIP 100 5% 1/8W
R27 1-216-234-00 RES,CHIP 33K 5% 1/8W
R28 1-216-174-00 RES,CHIP 100 5% 1/8W
R29 1-216-001-00 METAL CHIP 10 5% 1/10W
R32 1-216-093-91 RES,CHIP 68K 5% 1/10W
R33 1-216-033-00 METAL CHIP 220 5% 1/10W
R34 1-216-099-00 METAL CHIP 120K 5% 1/10W
R35 1-216-049-91 RES,CHIP 1K 5% 1/10W
R36 1-216-049-91 RES,CHIP 1K 5% 1/10W
R37 1-216-037-00 METAL CHIP 330 5% 1/10W
R39 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
MAIN
To Next Page
