SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
IT : Italian model
EA : Saudi Arabia model
CH : Chinese model
JE : Tourist model
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-3679-565-A MAIN BOARD, COMPLETE
(CND,AEP,IT,E,CH,EA)
*********************
* A-3679-765-A MAIN BOARD, COMPLETE (JE)
*********************
* A-3683-132-A MAIN BOARD, COMPLETE (US)
*********************
3-831-441-99 CUSHION, STOPPER
< CAPACITOR >
C1 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C4 1-163-377-11 CERAMIC CHIP 100PF 5% 50V
C5 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
C6 1-163-110-00 CERAMIC CHIP 51PF 5% 50V
C7 1-163-248-11 CERAMIC CHIP 75PF 5% 50V
C8 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C9 1-163-115-00 CERAMIC CHIP 82PF 5% 50V
C10 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C11 1-163-097-00 CERAMIC CHIP 15PF 5% 50V (JE)
C11 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
(US,CND,AEP,IT,E,CH,EA)
C12 1-163-096-00 CERAMIC CHIP 13PF 5% 50V
C13 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C14 1-163-091-00 CERAMIC CHIP 8PF 50V
C15 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C16 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C17 1-163-096-00 CERAMIC CHIP 13PF 5% 50V
C18 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C19 1-163-092-00 CERAMIC CHIP 9PF 0.25PF 50V
C20 1-163-224-11 CERAMIC CHIP 7PF 0.25PF 50V (JE)
C20 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
(US,CND,AEP,IT,E,CH,EA)
C21 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C22 1-163-108-00 CERAMIC CHIP 43PF 5% 50V
C23 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C24 1-163-367-11 CERAMIC CHIP 39PF 5% 50V
C25 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C26 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
C27 1-163-102-00 CERAMIC CHIP 24PF 5% 50V
C28 1-163-100-00 CERAMIC CHIP 20PF 5% 50V
C29 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
C30 1-163-063-00 CERAMIC CHIP 0.022uF 50V
C32 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C33 1-163-108-00 CERAMIC CHIP 43PF 5% 50V
C34 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C35 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C36 1-104-396-11 ELECT 10uF 20% 16V
C37 1-163-063-00 CERAMIC CHIP 0.022uF 50V
C38 1-163-087-00 CERAMIC CHIP 4PF 50V
(US,CND,AEP,IT,E,CH,EA)
C39 1-126-794-11 ELECT 4.7uF 20% 25V
C40 1-104-396-11 ELECT 10uF 20% 16V
C41 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C42 1-164-346-11 CERAMIC CHIP 1uF 16V
C43 1-126-794-11 ELECT 4.7uF 20% 25V
C44 1-126-794-11 ELECT 4.7uF 20% 25V
C45 1-104-396-11 ELECT 10uF 20% 16V
C46 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C47 1-163-074-00 CERAMIC CHIP 0.033uF 50V
C48 1-163-074-00 CERAMIC CHIP 0.033uF 50V
C49 1-164-346-11 CERAMIC CHIP 1uF 16V
C50 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C51 1-126-794-11 ELECT 4.7uF 20% 25V
C52 1-126-382-11 ELECT 100uF 20% 6.3V
C53 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C54 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C55 1-104-396-11 ELECT 10uF 20% 16V
C56 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C57 1-126-794-11 ELECT 4.7uF 20% 25V
C58 1-164-346-11 CERAMIC CHIP 1uF 16V
C59 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C60 1-126-935-11 ELECT 470uF 20% 6.3V
C61 1-126-382-11 ELECT 100uF 20% 6.3V
C62 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C63 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C64 1-126-794-11 ELECT 4.7uF 20% 25V
C65 1-164-346-11 CERAMIC CHIP 1uF 16V
C66 1-126-935-11 ELECT 470uF 20% 6.3V
C67 1-104-396-11 ELECT 10uF 20% 16V
C68 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C70 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C71 1-163-063-00 CERAMIC CHIP 0.022uF 50V
C72 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C73 1-163-087-00 CERAMIC CHIP 4PF 50V
C74 1-163-085-00 CERAMIC CHIP 2PF 50V (JE)
C75 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C80 1-163-033-91 CERAMIC CHIP 0.022uF 50V
C82 1-164-346-11 CERAMIC CHIP 1uF 16V
C90 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V(US)
C90 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
(CND,AEP,IT,E,JE,CH,EA)
C91 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V(US)
C91 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
(CND,AEP,IT,E,JE,CH,EA)
C92 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C93 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
MAIN
