Sony KDL-26S3000 Training Manual

CTV41 62
Chapter 3. Disassembly
REMOVE CN3008 FROM H4 BOARD
LIFT RIGHT SPEAKER OUT AND REST
ON POWER SUPPLY
LIFT U1 BOARD AND LEFT SPEAKER
OUT AND REST ON BU1 BOARD
FIGURE 3-4
26
/32 LCD PANEL REMOVAL (STEP 2)
FIGURE 3-4
26/32” PANEL REMOVAL (STEP 2)
