Sony KV-25F3A - 2 Disassembly; Rear Cover Removal; Chassis Assy Removal; Service Position

KV-25F3
— 20 —
DISASSEMBLY
SECTION 2
2-1. REAR COVER REMOVAL
3
Rear Cover
2-2. CHASSIS ASSY REMOVAL
2-3-1. SERVICE POSITION (1)
2-3-2. SERVICE POSITION (2)
Clip bracket into Beznet.
1 Snap off from main bracket.
Insert into heatsink.
2
1
One screw
(BVTP 4x16)
Four screws
(BVTP 4x16)
2
