— 77 —
KV-25F3
The components identified by
shading and marked are critical
for safety.
Replace only with the part number
specified.
Les composants identifies par
une trame et une marque sont
critiques pour la securite.
Ne les remplacer que par une piece
portant le numero specifie.
REF.NO. PART NO. DESCRIPTION REMARKREF.NO. PART NO. DESCRIPTION REMARK
A1
R1216 1-216-295-00 CONDUCTOR, CHIP
R1217 1-216-295-00 CONDUCTOR, CHIP
R1218 1-216-295-00 CONDUCTOR, CHIP
R1219 1-216-295-00 CONDUCTOR, CHIP
R1220 1-216-001-00 METAL GLAZE 10 5% 1/10W
R1221 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W
R1222 1-216-065-00 METAL GLAZE 4.7K 5% 1/10W
R1223 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R1224 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R1225 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1226 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R1227 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R1228 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1229 1-216-001-00 METAL GLAZE 10 5% 1/10W
R1230 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R1231 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R1232 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1233 1-216-061-00 METAL GLAZE 3.3K 5% 1/10W
R1234 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R1235 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1236 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1237 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1238 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1239 1-216-025-00 METAL GLAZE 100 5% 1/10W
R1240 1-216-295-00 CONDUCTOR, CHIP
***************************************************************
*A-1632-615-A A BOARD, COMPLETE (KV-25F3A)
*****************
*A-1632-617-A A BOARD, COMPLETE (KV-25F3B)
*****************
*A-1632-616-A A BOARD, COMPLETE (KV-25F3D)
*****************
*A-1632-614-A A BOARD, COMPLETE (KV-25F3E)
*****************
*A-1632-608-A A BOARD, COMPLETE (KV-25F3U)
*****************
1-750-797-11 SOCKET, PLCC
< CAPACITOR >
C1 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C2 1-126-967-11 ELECT 47MF 20% 16V
C3 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
C4 1-163-104-00 CERAMIC CHIP 30PF 5% 50V
C8 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C10 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C11 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C14 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C15 1-164-695-11 CERAMIC CHIP 0.0022MF 5% 50V
C18 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C19 1-163-017-00 CERAMIC CHIP 0.0047MF 10% 50V
C20 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C21 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C22 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C24 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C43 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C45 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C80 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C81 1-126-959-11 ELECT 0.47MF 20% 50V
C82 1-163-037-11 CERAMIC CHIP 0.022MF 10% 50V
C90 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C101 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C102 1-126-934-11 ELECT 220MF 20% 16V
C103 1-126-965-11 ELECT 22MF 20% 50V
C104 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C110 1-126-967-11 ELECT 47MF 20% 16V
C112 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C113 1-126-967-11 ELECT 47MF 20% 16V
C115 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C120 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C121 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C122 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C123 1-163-113-00 CERAMIC CHIP 68PF 5% 50V
C124 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C201 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C202 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V
C203 1-104-661-91 ELECT 330MF 20% 16V
C204 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C205 1-126-965-11 ELECT 22MF 20% 50V
C206 1-163-141-00 CERAMIC CHIP 0.001MF 5% 50V
C207 1-126-964-11 ELECT 10MF 20% 50V
C208 1-126-964-11 ELECT 10MF 20% 50V
C209 1-126-964-11 ELECT 10MF 20% 50V
C210 1-216-295-00 CONDUCTOR, CHIP
C211 1-126-964-11 ELECT 10MF 20% 50V
C212 1-164-346-11 CERAMIC CHIP 1MF 16V
C213 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C214 1-164-346-11 CERAMIC CHIP 1MF 16V
C215 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C216 1-126-967-11 ELECT 47MF 20% 16V
C217 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C218 1-126-967-11 ELECT 47MF 20% 16V
C219 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C220 1-126-964-11 ELECT 10MF 20% 50V
C221 1-164-505-11 CERAMIC CHIP 2.2MF 16V
C222 1-164-346-11 CERAMIC CHIP 1MF 16V
C223 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C224 1-164-346-11 CERAMIC CHIP 1MF 16V
C225 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C226 1-126-967-11 ELECT 47MF 20% 16V
C227 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C228 1-126-967-11 ELECT 47MF 20% 16V
C229 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V
C230 1-216-295-00 CONDUCTOR, CHIP
C231 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C232 1-126-962-11 ELECT 3.3MF 20% 50V
C240 1-164-346-11 CERAMIC CHIP 1MF 16V
C241 1-164-346-11 CERAMIC CHIP 1MF 16V
C251 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C252 1-163-087-00 CERAMIC CHIP 4PF 0.25PF 50V
C253 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C254 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C255 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C256 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C257 1-126-965-11 ELECT 22MF 20% 50V
C258 1-126-964-11 ELECT 10MF 20% 50V
C259 1-164-336-11 CERAMIC CHIP 0.33MF 25V
C260 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C261 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C262 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C263 1-163-038-00 CERAMIC CHIP 0.1MF 25V
C264 1-126-962-11 ELECT 3.3MF 20% 50V
