NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3021-100-A LED BOARD, COMPLETE
********************
1-669-666-11 LED FLEXIBLE BOARD
< CAPACITOR >
C501 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C502 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
< DIODE >
D401 8-719-985-81 LED HLMP-Q150 (REC)
D501 8-719-062-42 LED BR1111R-TR (BATT • •)
D502 8-719-062-42 LED BR1111R-TR (BATT • )
D503 8-719-062-43 LED AY1111R-TR (i)
< IC >
IC501 8-759-399-49 IC MM1251BFBE
< COIL >
L501 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q501 8-729-402-93 TRANSISTOR UN5214-TX
< RESISTOR >
R501 1-216-106-00 METAL CHIP 240K 5% 1/10W
R502 1-216-101-00 METAL CHIP 150K 5% 1/10W
R503 1-216-083-00 METAL CHIP 27K 5% 1/10W
R504 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R505 1-216-033-00 METAL CHIP 220 5% 1/10W
R506 1-216-037-00 METAL CHIP 330 5% 1/10W
R507 1-216-037-00 METAL CHIP 330 5% 1/10W
R508 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R509 1-216-045-00 METAL CHIP 680 5% 1/10W
< SWITCH >
S102 1-570-386-11 SWITCH, SLIDE (SENSITIVITY)
************************************************************
A-3021-101-A MAIN BOARD, COMPLETE
*********************
3-025-037-01 TERMINAL, BATTERY
3-025-038-01 SPRING, BATTERY COIL
< CAPACITOR >
C101 1-164-346-11 CERAMIC CHIP 1uF 16V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C104 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-164-346-11 CERAMIC CHIP 1uF 16V
C106 1-126-607-11 ELECT CHIP 47uF 20% 4V
C107 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C108 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C109 1-164-346-11 CERAMIC CHIP 1uF 16V
C110 1-163-037-11 CERAMIC CHIP 0.022uF 50V
C111 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C112 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C113 1-164-346-11 CERAMIC CHIP 1uF 16V
C114 1-164-346-11 CERAMIC CHIP 1uF 16V
C115 1-164-346-11 CERAMIC CHIP 1uF 16V
C116 1-124-779-00 ELECT CHIP 10uF 20% 16V
C117 1-128-024-11 ELECT CHIP 4.7uF 20% 10V
C118 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C119 1-128-015-11 ELECT CHIP 22uF 20% 4V
C120 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C121 1-164-346-11 CERAMIC CHIP 1uF 16V
C122 1-164-346-11 CERAMIC CHIP 1uF 16V
C123 1-164-346-11 CERAMIC CHIP 1uF 16V
C124 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C125 1-126-246-11 ELECT CHIP 220uF 20% 4V
C126 1-126-209-11 ELECT CHIP 100uF 20% 4V
C127 1-126-246-11 ELECT CHIP 220uF 20% 4V
C128 1-124-779-00 ELECT CHIP 10uF 20% 16V
C129 1-164-699-11 CERAMIC CHIP 0.0033uF 5% 50V
C130 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C131 1-163-010-11 CERAMIC CHIP 0.0012uF 10% 50V
C132 1-126-607-11 ELECT CHIP 47uF 20% 4V
C133 1-164-346-11 CERAMIC CHIP 1uF 16V
C134 1-164-346-11 CERAMIC CHIP 1uF 16V
C135 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C136 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C137 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C138 1-164-346-11 CERAMIC CHIP 1uF 16V
C140 1-164-346-11 CERAMIC CHIP 1uF 16V
C141 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C142 1-163-038-91 CERAMIC CHIP 0.1uF 25V
• Abbreviation
E :Indication of country of origin
1E :No indication of country of origin
LED MAIN
