Sony MDS-S39 - Electrical Parts List; Difference Table - Electrical Parts

– 7 –
* A-4724-483-A MAIN BOARD, COMPLETE (JE)
* A-4699-952-A MAIN BOARD, COMPLETE (AEP, UK)
* A-4699-949-A MAIN BOARD, COMPLETE (US, CND)
* A-4699-955-A MAIN BOARD, COMPLETE (SP)
* A-4724-153-A MAIN BOARD, COMPLETE (HK)
R414 Not used
R415 1-249-429-11 CARBON 10K 5% 1/4W
S303 1-762-175-11 SWITCH, SLIDE (BEEP)
* A-4724-484-A PANEL BOARD, COMPLETE (JE)
* A-4699-953-A PANEL BOARD, COMPLETE (AEP, UK)
* A-4699-950-A PANEL BOARD, COMPLETE (US, CND)
* A-4699-956-A PANEL BOARD, COMPLETE (SP)
* A-4724-154-A PANEL BOARD, COMPLETE (HK)
BP701 1-529-104-11 BUZZER, PIEZOELECTRIC
FL701 1-517-768-11 INDICATOR TUBE, FLUORESCENT
Q783 8-729-422-57 TRANSISTOR UN4111
Q784 8-729-422-57 TRANSISTOR UN4111
R703 1-249-427-11 CARBON 6.8K 5% 1/4W
R704 1-249-427-11 CARBON 6.8K 5% 1/4W
R718 Not used
ACCESSORIES & PACKING MATERIALS
*******************************
1-475-676-11 REMOTE COMMANDER (RM-D27M)
1-776-263-51 CORD, CONNECTION (AUDIO)
3-862-110-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH)
3-862-110-21 MANUAL, INSTRUCTION
(CHINESE, PORTUGUESE) (AEP, SP, JE)
3-862-110-31 MANUAL, INSTRUCTION
(DUTCH, ITALIAN, GERMAN) (AEP)
3-862-110-41 MANUAL, INSTRUCTION
(DANISH, FINNISH, SWEDISH) (AED)
3. ELECTRICAL PARTS LIST
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• Abbreviation
AED : North European
CND : Canadian
HK : Hong Kong
JE : Tourist
SP : Singapore
• DIFFERENCE TABLE
83
Page MDS-S38 MDS-S39
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4699-641-A MAIN BOARD, COMPLETE (JE)
* A-4699-714-A MAIN BOARD, COMPLETE (AEP, UK)
* A-4699-717-A MAIN BOARD, COMPLETE (US, CND)
* A-4699-720-A MAIN BOARD, COMPLETE (SP)
* A-4699-723-A MAIN BOARD, COMPLETE (HK)
R414 1-249-429-11 CARBON 10K 5% 1/4W
R415 Not used
S303 Not used
* A-4699-645-A PANEL BOARD, COMPLETE (JE)
* A-4699-715-A PANEL BOARD, COMPLETE (AEP, UK)
* A-4699-718-A PANEL BOARD, COMPLETE (US, CND)
* A-4699-721-A PANEL BOARD, COMPLETE (SP)
* A-4699-724-A PANEL BOARD, COMPLETE (HK)
BP701 Not used
FL701 1-517-575-11 INDICATOR TUBE, FLUORESCENT
Q783 Not used
Q784 Not used
R703 Not used
R704 Not used
R718 1-249-435-11 CARBON 33K 5% 1/4W
ACCESSORIES & PACKING MATERIALS
*******************************
1-473-785-11 REMOTE COMMANDER (RM-D8M)
1-776-263-11 CORD, CONNECTION (AUDIO)
3-859-426-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH)
3-859-426-21 MANUAL, INSTRUCTION
(CHINESE, PORTUGUESE) (AEP, SP)
3-859-426-31 MANUAL, INSTRUCTION
(DUTCH, ITALIAN, GERMAN) (AEP)
3-859-426-41 MANUAL, INSTRUCTION
(DANISH, FINNISH, SWEDISH) (AED)
