Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MEX-BT4100E/BT4100P/BT4100U/BT4150U
1313
C792 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C794 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C796 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C797 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C798 1-116-728-11 CERAMIC CHIP 2.2uF 10% 10V
C801 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C830 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
(BT4100P)
C831 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
(BT4100P)
C876 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
(BT4100P)
C877 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
(BT4100P)
C878 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
(BT4100P)
C1301 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C1304 1-116-705-11 CERAMIC CHIP 47uF 20% 16V
C1305 1-100-055-21 CERAMIC CHIP 22uF 20% 16V
C1306 1-164-936-11 CERAMIC CHIP 680PF 10% 50V
C1307 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C1308 1-114-983-91 CERAMIC CHIP 2.2uF 10% 16V
C1309 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C1310 1-114-582-91 CERAMIC CHIP 0.1uF 10% 16V
C1311 1-117-681-11 ELECT CHIP 100uF 20% 16V
C1312 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C1315 1-100-055-21 CERAMIC CHIP 22uF 20% 16V
C1316 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C1318 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1320 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C1325 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C1326 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C1327 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
< TUNER UNIT/CONNECTOR >
CN01 A-1878-198-A TUX-DSP02 (TUNER UNIT)
CN102 1-842-266-22 SOCKET, CONNECTOR 20P
CN301 1-843-330-11 PIN, CONNECTOR 16P
CN700 1-842-487-12 CONNECTOR, BOARD TO BOARD 28P
CN802 1-779-886-11 SOCKET, MINIATURE DIN CONNECTOR
(SIRIUSXM IN) (BT4100P)
< DIODE >
D114 6-503-205-01 DIODE RKZ6.8B2KGP1
D115 6-503-205-01 DIODE RKZ6.8B2KGP1
D119 6-503-205-01 DIODE RKZ6.8B2KGP1
D306 6-503-238-01 DIODE GN1G (BT4100U)
D307 6-503-213-01 DIODE RKZ18B2KGP1
D308 6-502-961-01 DIODE DA2J10100L
D318 6-503-238-01 DIODE GN1G
D321 6-503-238-01 DIODE GN1G
D323 6-503-213-01 DIODE RKZ18B2KGP1
D324 6-503-238-01 DIODE GN1G
D401 6-502-961-01 DIODE DA2J10100L
D530 6-503-759-01 DIODE RB751V40, 115
D602 6-503-759-01 DIODE RB751V40, 115
D805 6-503-206-01 DIODE RKZ7.5B2KGP1
D806 6-503-213-01 DIODE RKZ18B2KGP1
D820 6-503-213-01 DIODE RKZ18B2KGP1 (BT4100P)
D830 6-503-213-01 DIODE RKZ18B2KGP1 (BT4100P)
D831 6-503-213-01 DIODE RKZ18B2KGP1 (BT4100P)
D832 6-503-213-01 DIODE RKZ18B2KGP1 (BT4100P)
D1300 6-503-548-01 DIODE DB2441600L
< FUSE >
F3 1-576-415-11 FUSE (2 A/32 V) (BT4100P)
< FERRITE BEAD/JUMPER RESISTOR >
FB19 1-400-334-21 FERRITE, EMI (SMD) (1608) (BT4100P)
FB306 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB314 1-481-051-21 BEAD, FERRITE (CHIP) (1608)
FB398 1-469-084-21 INDUCTOR, FERRITE BEAD (1005)
FB404 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB405 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB406 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB407 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB408 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB410 1-400-040-22 BEAD, FERRITE (CHIP) (1608)
FB411 1-400-632-21 BEAD, FERRITE (1005)
FB412 1-400-632-21 BEAD, FERRITE (1005)
FB413 1-400-632-21 BEAD, FERRITE (1005)
FB414 1-400-632-21 BEAD, FERRITE (1005)
FB415 1-400-632-21 BEAD, FERRITE (1005)
FB416 1-481-051-21 BEAD, FERRITE (CHIP) (1608)
FB420 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB501 1-414-595-11 INDUCTOR, FERRITE BEAD
FB722 1-218-990-81 SHORT CHIP 0
FB724 1-469-084-21 INDUCTOR, FERRITE BEAD (1005)
FB782 1-469-084-21 INDUCTOR, FERRITE BEAD (1005)
FB801 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB802 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB803 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB890 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB891 1-500-113-22 BEAD, FERRITE (CHIP) (1608)
FB1301 1-216-864-11 SHORT CHIP 0
< IC >
IC301 6-715-848-21 IC TDF8556AJ/N5
IC401 6-714-623-01
IC BD3467FV-E2
IC402 6-720-463-01 IC MM1886A33NRE
IC501 6-719-019-02 IC R5F3650ECDZ98FB (for SERVICE)
(BT4100E/BT4100U/BT4150U)
IC501 6-719-022-02 IC R5F3650KCDZ95FB (for SERVICE) (BT4100P)
IC601 6-715-714-01 IC TMPM320C1DFG-9999
IC602 6-719-044-02 IC W25Q16CVSSIG-A02 (for SERVICE)
IC603 6-717-694-01 IC BU33TD3WG-TR
IC681 6-716-355-01 IC BU15TD3WG-TR
IC682 6-716-355-01 IC BU15TD3WG-TR
IC701 6-715-712-11 IC TC94A99FG-003 (SY, H
IC703 6-715-716-01 IC S-1206B12-U3T1G
IC704 6-718-324-01 IC MFI337S3959
IC830 6-710-376-01 IC 74LVC1G17GW-125 (BT4100P)
IC831 6-709-182-01 IC TC7WH126FK (BT4100P)
IC1300 6-718-913-01 IC OZ539IGN-A1-0-TR
< JACK >
J1 1-843-172-1
1 JACK (ANT) (ANTENNA IN)
J403 1-822-714-21 JACK, PIN 6P
(FRONT/REAR AUDIO OUT, SUB OUT (MONO))
J801 1-566-822-81 JACK (REMOTE IN)
Note: When IC501 is replaced, the destination setting is necessary. Refer
to “NOTE THE MAIN BOARD OR SYSTEM CONTROLLER
(IC501) REPLACING” on page 4 on original service manual.
MAIN
To Next Page
