Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MEX-BT4100E/BT4100P/BT4100U/BT4150U
14
< COIL >
L1 1-400-073-21 INDUCTOR 4.7uH
L301 1-460-443-11 CHOKE COIL 140uH
L395 1-469-844-11 INDUCTOR 2.2uH
L431 1-469-844-11 INDUCTOR 2.2uH
L1301 1-457-630-11 COIL, CHOKE 47uH
< TRANSISTOR >
Q301 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q302 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q401 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q402 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q403 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q404 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q405 6-552-937-01 TRANSISTOR LTC014TUBFS8TL
Q407 6-552-922-01 TRANSISTOR LTA014EUBFS8TL
Q408 6-552-922-01 TRANSISTOR LTA014EUBFS8TL (Suffi x-22)
Q409 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q710 6-551-120-01 TRANSISTOR 2SA2119K
Q801 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q802 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q803 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
< RESISTOR/CAPACITOR >
R10 1-218-990-81 SHORT CHIP 0
R13 1-216-821-11 METAL CHIP 1K 5% 1/10W
R19 1-216-864-11 SHORT CHIP 0 (BT4100E/BT4100U/BT4150U)
R100 1-216-864-11 SHORT CHIP 0
R101 1-216-296-11 SHORT CHIP 0
R102 1-216-864-11 SHORT CHIP 0
R107 1-216-296-11 SHORT CHIP 0
R116 1-216-864-11 SHORT CHIP 0
R200 1-216-864-11 SHORT CHIP 0
R201 1-216-295-91 SHORT CHIP 0
R203 1-216-864-11 SHORT CHIP 0
R300 1-216-296-11 SHORT CHIP 0
R301 1-218-941-81 METAL CHIP 100 5% 1/16W
R302 1-218-941-81 METAL CHIP 100 5% 1/16W
R303 1-216-182-00 METAL CHIP 220 5% 1/8W
R304 1-216-182-00 METAL CHIP 220 5% 1/8W
R305 1-216-182-00 METAL CHIP 220 5% 1/8W
R306 1-216-182-00 METAL CHIP 220 5% 1/8W
R307 1-218-943-11 METAL CHIP 150 5% 1/16W
R308 1-216-864-11 SHORT CHIP 0
R309 1-218-973-11 METAL CHIP 47K 5% 1/16W
R310 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
R311 1-216-073-91 METAL CHIP 10K 5% 1/10W
R312 1-218-973-11 METAL CHIP 47K 5% 1/16W
R313 1-218-973-11 METAL CHIP 47K 5% 1/16W
R314 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R315 1-218-969-11 METAL CHIP 22K 5% 1/16W
R316 1-218-977-11 METAL CHIP 100K 5% 1/16W
R317 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R322 1-216-296-11 SHORT CHIP 0
R323 1-216-821-11 METAL CHIP 1K 5% 1/10W
R324 1-216-821-11 METAL CHIP 1K 5% 1/10W
R325 1-216-821-11 METAL CHIP 1K 5% 1/10W
R326 1-216-821-11 METAL CHIP 1K 5% 1/10W
R340 1-216-864-11 SHORT CHIP 0
R378 1-216-073-91 METAL CHIP 10K 5% 1/10W
R387 1-216-864-11 SHORT CHIP 0
R396 1-216-296-11 SHORT CHIP 0
R400 1-216-864-11 SHORT CHIP 0
R404 1-218-945-11 METAL CHIP 220 5% 1/16W
R405 1-216-841-11 METAL CHIP 47K 5% 1/10W
R407 1-218-945-11 METAL CHIP 220 5% 1/16W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-218-945-11 METAL CHIP 220 5% 1/16W
R411 1-216-833-11 METAL CHIP 10K 5% 1/10W
R412 1-218-990-81 SHORT CHIP 0
R415 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-821-11 METAL CHIP 1K 5% 1/10W
R417 1-218-966-11 METAL CHIP 12K 5% 1/16W
R418 1-218-966-11 METAL CHIP 12K 5% 1/16W
R419 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R421 1-218-945-11 METAL CHIP 220 5% 1/16W
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R423 1-218-945-11 METAL CHIP 220 5% 1/16W
R424 1-216-833-11 METAL CHIP 10K 5% 1/10W
R425 1-216-864-11 SHORT CHIP 0
R426 1-216-296-11 SHORT CHIP 0
R427 1-218-990-81 SHORT CHIP 0
R429 1-218-933-11 METAL CHIP 22 5% 1/16W
R432 1-218-965-11 METAL CHIP 10K 5% 1/16W
R433 1-216-296-11 SHORT CHIP 0
R434 1-216-295-91 SHORT CHIP 0
R442 1-216-864-11 SHORT CHIP 0
R443 1-216-864-11 SHORT CHIP 0
R444 1-216-864-11 SHORT CHIP 0
R445 1-216-864-11 SHORT CHIP 0
R446 1-216-864-11 SHORT CHIP 0
R462 1-216-864-11 SHORT CHIP 0
R463 1-216-864-11 SHORT CHIP 0
R464 1-216-864-11 SHORT CHIP 0
R465 1-216-864-11 SHORT CHIP 0
R466 1-216-864-11 SHORT CHIP 0
R468 1-216-864-11 SHORT CHIP 0
R469 1-216-864-11 SHORT CHIP 0
R470 1-216-864-11 SHORT CHIP 0
R471 1-216-864-11 SHORT CHIP 0
R472 1-216-864-11 SHORT CHIP 0
R473 1-216-864-11 SHORT CHIP 0
R490 1-216-813-11 METAL CHIP 220 5% 1/10W
R491 1-216-813-11 METAL CHIP 220 5% 1/10W
R492 1-216-813-11 METAL CHIP 220 5% 1/10W
R493 1-216-813-11 METAL CHIP 220 5% 1/10W
R494 1-216-813-11 METAL CHIP 220 5% 1/10W
R495 1-216-813-11 METAL CHIP 220 5% 1/10W
R502 1-218-977-11 METAL CHIP 100K 5% 1/16W
R505 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R506 1-218-981-91 METAL CHIP 220K 5% 1/16W
R507 1-218-977-11 METAL CHIP 100K 5% 1/16W
R510 1-216-809-11 METAL CHIP 100 5% 1/10W
R511 1-216-809-11 METAL CHIP 100 5% 1/10W
R514 1-250-519-11 METAL CHIP 10K 1% 1/16W
R515 1-250-519-11 METAL CHIP 10K 1% 1/16W
R516 1-250-519-11 METAL CHIP 10K 1% 1/16W
R517 1-218-953-11 METAL CHIP 1K 5% 1/16W
R518 1-218-953-11 METAL CHIP 1K 5% 1/16W
R521 1-218-971-11 METAL CHIP 33K 5% 1/16W
MAIN
Note: Refer to “MAIN BOARD DISCRIMINATION” on page 1 for
how to distinguish Suffi x-21 and Suffi x-22 of the MAIN board.
