model name [MHC-V4D]
[4-540-486-12(1)] GB
51
GB
filename[D:\NORM'S JOB\SONY HA\SO140051\MHC-V4D_PMRF
02\4540486121_GB\090INF.fm]
masterpage:Right
Additional Information
Bluetooth devices and wireless LAN
(IEEE 802.11b/g) use the same frequency
band (2.4 GHz). When using your Bluetooth
device near a device with wireless LAN
capability, electromagnetic interference may
occur. This could result in lower data transfer
rates, noise, or inability to connect. If this
happens, try the following remedies:
Try connecting this system and Bluetooth
device when you are at least 10 meters away
from the wireless LAN equipment.
Turn off the power to the wireless LAN
equipment when using your Bluetooth
device within 10 meters.
The radio waves broadcast by this system may
interfere with the operation of some medical
devices. Since this interference may result in
malfunction, always turn off the power on this
system and Bluetooth device in the following
locations:
In hospitals, on trains, in airplanes, at gas
stations, and any place where flammable
gases may be present.
Near automatic doors or fire alarms.
This system supports security functions that
comply with the Bluetooth specification as a
means of ensuring security during
communication using Bluetooth technology.
However, this security may be insufficient
depending on the setting contents and other
factors, so always be careful when performing
communication using Bluetooth technology.
Sony cannot be held liable in any way for
damages or other loss resulting from
information leaks during communication
using Bluetooth technology.
Bluetooth communication is not necessarily
guaranteed with all Bluetooth devices that
have the same profile as this system.
Bluetooth devices connected with this system
must comply with the Bluetooth specification
prescribed by the Bluetooth SIG, Inc., and
must be certified to comply. However, even
when a device complies with the Bluetooth
specification, there may be cases where the
characteristics or specifications of the
Bluetooth device make it impossible to
connect, or may result in different control
methods, display or operation.
Noise may occur or the audio may cut off
depending on the Bluetooth device connected
with this system, the communications
environment, or surrounding conditions.
Specifications
Amplifier section
The following are measured at AC 120 V –
240 V, 50/60 Hz
Power output (rated)
Left/Right Channel: 120 W + 120 W
(at 2 ohms, 1 kHz, 1% THD)
RMS output power (reference)
Left/Right Channel: 180 W + 180 W
(per channel at 2 ohms, 1 kHz)
Subwoofer: 360 W (at 4 ohms, 100 Hz)
Inputs
AUDIO IN L/R
Voltage 2 V, impedance 47 kilohms
MIC 1, MIC 2
Sensitivity 1 mV, impedance
10 kilohms
(USB) port
Type A
Outputs
VIDEO OUT
Max. output level 1 Vp-p, unbalanced,
Sync. negative load impedance
75 ohms
USB section
Supported bit rate
WMA: 48 kbps – 192 kbps, VBR,
CBR
AAC: 48 kbps – 320 kbps, VBR, CBR
Sampling frequencies
WMA: 44.1 kHz
AAC: 44.1 kHz
Supported USB device
Mass Storage Class
Maximum current
500 mA

Other manuals for Sony MHC-V4D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony MHC-V4D and is the answer not in the manual?

Sony MHC-V4D Specifications

General IconGeneral
TypeHome audio mini system
Cassette deckNo
Product colorBlack
Optical disc playerYes
Number of optical discs1 discs
Bass reflex-
Speaker type3-way
RMS rated power720 W
Woofer diameter200 mm
Tweeter diameter40 mm
Number of speakers5
Mid-range driver diameter100 mm
Equalizer modesCustom, Pop, Flat, Rap, Rock
FM band range87.5 - 108 MHz
Supported radio bandsFM
Power sourceAC
Input voltage120-240 V
Input frequency50 - 60 Hz
Composite video out1
Apple docking compatibilityNot supported
On Screen Display (OSD) languagesEnglish
Playback modesProgram, Shuffle, Repeat, Normal
Audio formats supportedWMA, MP3
Display typeLCD
Weight and Dimensions IconWeight and Dimensions
Depth295 mm
Width280 mm
Height780 mm
