MVC-CD200/CD300
SECTION 2
DISASSEMBLY
The following flow chart shows the disassembly procedure.
2-16.MD-083 BOARD
NOTE: Follow the disassembly procedure in the numerical order given.
2-8. Base unit (DDX-G2100 complete assembly)
2-16. MD-083 board
After performing “Disassembly” Section 2-7
SY-67 board of MVC-CD200/CD300
Service Manual Level 2 (page 2-7),
do the following.
2-7. SY-67 board
MD-083 board service position
Refer to level 2
M
D
-083
M
D
-0
8
3
SY-
67
JK-
208
SY-
67
JK-
208
SY-
67
JK-
208
M
D
-0
8
3
M
D-
083
1 Harness (FS-138) (2P)
(door lock plunger)
2 Flexible board
(from spindle motor 18P)
5 Remove the MD heat sink
in the direction of the arrow A.
4 Dowel
6 MD
heat sink
7
3 Precision
screw
(DIA 1.7 × 4)
1 Precision
screw
(DIA 1.7 × 4)
3 MD-083 board
2 Remove the MD-083 board in the direction
of the arrow BC.
A
B
C
4 MD-083 board
2 Flexible board
(from optical device)
(32P)
1 Flexible
retainer
3 Ferrite core
4
5
