6-16
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< DIODE >
D002 8-719-801-78 DIODE 1S2837-T1
D004 8-719-070-20 DIODE RB706F-40
D007 8-719-800-76 DIODE 1SS123-T1
D008 8-719-801-78 DIODE 1S2837-T1
D200 8-719-988-82 DIODE RB715F-T106
D204 8-719-988-61 DIODE 1SS355TE-17
D205 8-719-988-82 DIODE RB715F-T106
D405 8-719-988-61 DIODE 1SS355TE-17
D406 8-719-988-61 DIODE 1SS355TE-17
D407 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB001 1-216-864-11 METAL CHIP 0 5% 1/16W
(Note)
FB002 1-414-921-11 FERRITE 0uH
FB004 1-216-864-11 METAL CHIP 0 5% 1/16W
(Note)
FB405 1-500-449-21 FERRITE 0uH
FB406 1-500-449-21 FERRITE 0uH
FB407 1-414-228-11 FERRITE 0uH
FB408 1-414-228-11 FERRITE 0uH
FB409 1-500-329-21 FERRITE 0uH
FB410 1-500-449-21 FERRITE 0uH
< IC >
IC001 8-759-571-65 IC BH6520AFV-E2
IC002 8-759-485-79 IC TC7SET08FU(TE85R)
IC003 8-759-571-69 IC LB11998V-TLM
IC004 8-759-481-08 IC TC7SET02FU(TE85R)
IC005 8-759-571-64 IC BH6521FV-E2
IC006 8-759-485-79 IC TC7SET08FU(TE85R)
IC007 8-759-075-66 IC TA75S01F(TE85R)
IC009 8-759-234-77 IC BU4S66-TR
IC010 8-759-075-66 IC TA75S01F(TE85R)
IC011 8-759-234-77 IC BU4S66-TR
IC012 8-759-448-71 IC BU4053BCFV-E2
IC013 8-759-677-23 IC AK8564A
IC013 8-759-677-23 IC AK8564A-H
IC014 8-759-685-64 IC CXA8094AR
IC015 8-759-234-77 IC BU4S66-TR
IC019 8-759-064-36 IC MB88346BPFV-EF
IC022 8-759-075-70 IC TA75S393F-TE85R
IC200 8-759-058-43 IC NJM3404AV(TE2)
IC201 8-752-392-44 IC CXD3021R
IC204 8-759-234-77 IC BU4S66-TR
IC207 8-752-403-97 IC CXD1457R
IC208 8-759-066-55 IC TA75W393FU-TE12R
IC209 8-759-570-08 IC TC7SET32FU(TE85R)
IC400 8-759-083-94 IC TC7W74FU(TE12R)
IC401 8-759-561-40 IC TC55V1001AFTI-10L(YEL)
IC402 8-759-594-71 IC TC7SH14FU-TE85R
IC403 8-759-196-97 IC TC7SH32FU-TE85R
IC404 8-759-835-15 IC HD64F2314VTE25
IC406 8-759-566-20 IC AK6440BH-E2
IC407 8-759-392-77 IC TC74LCX245FT(EL)
IC408 8-759-579-83 IC K4F160811D-BC50T
IC408 8-759-683-32 IC K4F160811D-BC60T
IC410 8-759-058-60 IC TC7SU04FU(TE85R)
IC413 8-759-058-60 IC TC7SU04FU(TE85R)
IC414 8-759-570-49 IC CL-CR3465-48SC-C
IC418 8-759-196-97 IC TC7SH32FU-TE85R
IC419 8-759-196-97 IC TC7SH32FU-TE85R
IC422 8-759-196-97 IC TC7SH32FU-TE85R
IC423 8-759-196-96 IC TC7SH08FU-TE85R
IC425 8-759-485-77 IC BA9743AFV-E2
< COIL >
L001 1-469-522-91 INDUCTOR 1uH
L202 1-469-525-91 INDUCTOR 10uH
L402 1-469-525-91 INDUCTOR 10uH
L403 1-414-410-21 INDUCTOR 10uH
L405 1-419-368-21 INDUCTOR 47uH
L406 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q003 8-729-042-60 TRANSISTOR UN9114J-(K8).SO
Q004 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q006 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q008 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q009 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q013 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q203 8-729-037-61 TRANSISTOR UN9113J-(K8).SO
Q204 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q402 8-729-044-84 TRANSISTOR CPH3403-TL
Q403 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q404 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q407 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q409 8-729-047-90 TRANSISTOR XP162A11C0PR
Q410 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q411 8-729-030-78 TRANSISTOR FP102T-TL
Q412 8-729-013-31 TRANSISTOR 2SA1588-OY-TE85L
Q416 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q417 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
Q418 8-729-046-77 TRANSISTOR SI4963DY-T1
< RESISTOR >
R004 1-218-990-11 SHORT 0
R007 1-218-990-11 SHORT 0
R011 1-218-941-11 RES-CHIP 100 5% 1/16W
R012 1-217-907-11 RES-CHIP 1.8 5% 1/10W
R013 1-217-907-11 RES-CHIP 1.8 5% 1/10W
R016 1-217-907-11 RES-CHIP 1.8 5% 1/10W
R017 1-218-973-11 RES-CHIP 47K 5% 1/16W
R018 1-218-990-11 SHORT 0
R020 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R021 1-218-990-11 SHORT 0
R022 1-218-990-11 SHORT 0
R024 1-218-990-11 SHORT 0
R029 1-218-965-11 RES-CHIP 10K 5% 1/16W
R030 1-218-973-11 RES-CHIP 47K 5% 1/16W
R034 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
R035 1-218-949-11 RES-CHIP 470 5% 1/16W
R036 1-218-965-11 RES-CHIP 10K 5% 1/16W
R042 1-218-973-11 RES-CHIP 47K 5% 1/16W
R043 1-218-945-11 RES-CHIP 220 5% 1/16W
R044 1-218-973-11 RES-CHIP 47K 5% 1/16W
MD-083
Note : Resistors are mounted to the location where FB001, FB004
are printed.
