6-18
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R318 1-218-973-11 RES-CHIP 47K 5% 1/16W
R319 1-218-965-11 RES-CHIP 10K 5% 1/16W
R322 1-218-977-11 RES-CHIP 100K 5% 1/16W
R323 1-218-977-11 RES-CHIP 100K 5% 1/16W
R324 1-218-977-11 RES-CHIP 100K 5% 1/16W
R326 1-218-977-11 RES-CHIP 100K 5% 1/16W
R328 1-218-990-11 SHORT 0
R329 1-218-990-11 SHORT 0
R400 1-218-965-11 RES-CHIP 10K 5% 1/16W
R403 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R404 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R405 1-218-973-11 RES-CHIP 47K 5% 1/16W
R406 1-218-973-11 RES-CHIP 47K 5% 1/16W
R407 1-218-977-11 RES-CHIP 100K 5% 1/16W
R409 1-218-973-11 RES-CHIP 47K 5% 1/16W
R410 1-218-977-11 RES-CHIP 100K 5% 1/16W
R411 1-218-969-11 RES-CHIP 22K 5% 1/16W
R451 1-218-973-11 RES-CHIP 47K 5% 1/16W
R454 1-218-977-11 RES-CHIP 100K 5% 1/16W
R464 1-218-973-11 RES-CHIP 47K 5% 1/16W
R473 1-218-990-11 SHORT 0
R478 1-218-990-11 SHORT 0
R488 1-218-977-11 RES-CHIP 100K 5% 1/16W
R493 1-218-977-11 RES-CHIP 100K 5% 1/16W
R497 1-218-977-11 RES-CHIP 100K 5% 1/16W
R545 1-218-977-11 RES-CHIP 100K 5% 1/16W
R546 1-218-977-11 RES-CHIP 100K 5% 1/16W
R547 1-218-977-11 RES-CHIP 100K 5% 1/16W
R548 1-218-977-11 RES-CHIP 100K 5% 1/16W
R549 1-218-977-11 RES-CHIP 100K 5% 1/16W
R551 1-218-953-11 RES-CHIP 1K 5% 1/16W
R552 1-218-977-11 RES-CHIP 100K 5% 1/16W
R563 1-218-989-11 RES-CHIP 1M 5% 1/16W
R576 1-218-989-11 RES-CHIP 1M 5% 1/16W
R580 1-218-973-11 RES-CHIP 47K 5% 1/16W
R586 1-218-990-11 SHORT 0
R587 1-218-973-11 RES-CHIP 47K 5% 1/16W
R588 1-218-973-11 RES-CHIP 47K 5% 1/16W
R593 1-218-941-11 RES-CHIP 100 5% 1/16W
R594 1-218-949-11 RES-CHIP 470 5% 1/16W
R595 1-218-949-11 RES-CHIP 470 5% 1/16W
R596 1-218-949-11 RES-CHIP 470 5% 1/16W
R597 1-218-941-11 RES-CHIP 100 5% 1/16W
R598 1-218-949-11 RES-CHIP 470 5% 1/16W
R599 1-218-949-11 RES-CHIP 470 5% 1/16W
R600 1-218-949-11 RES-CHIP 470 5% 1/16W
R601 1-218-949-11 RES-CHIP 470 5% 1/16W
R602 1-218-949-11 RES-CHIP 470 5% 1/16W
R605 1-218-965-11 RES-CHIP 10K 5% 1/16W
R606 1-218-965-11 RES-CHIP 10K 5% 1/16W
R607 1-218-965-11 RES-CHIP 10K 5% 1/16W
R608 1-218-965-11 RES-CHIP 10K 5% 1/16W
R611 1-216-295-91 SHORT 0
R631 1-218-945-11 RES-CHIP 220 5% 1/16W
R632 1-218-945-11 RES-CHIP 220 5% 1/16W
R634 1-218-990-11 SHORT 0
R635 1-218-990-11 SHORT 0
R637 1-218-939-11 RES-CHIP 68 5% 1/16W
R638 1-218-977-11 RES-CHIP 100K 5% 1/16W
R640 1-218-977-11 RES-CHIP 100K 5% 1/16W
R654 1-218-973-11 RES-CHIP 47K 5% 1/16W
R655 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R656 1-218-971-11 RES-CHIP 33K 5% 1/16W
R657 1-218-953-11 RES-CHIP 1K 5% 1/16W
R658 1-218-970-11 METAL CHIP 27K 0.5% 1/16W
R659 1-218-953-11 RES-CHIP 1K 5% 1/16W
R661 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R663 1-218-965-11 RES-CHIP 10K 5% 1/16W
R664 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R668 1-218-965-11 RES-CHIP 10K 5% 1/16W
R672 1-218-965-11 RES-CHIP 10K 5% 1/16W
R673 1-218-969-11 RES-CHIP 22K 5% 1/16W
R674 1-218-973-11 RES-CHIP 47K 5% 1/16W
R675 1-218-973-11 RES-CHIP 47K 5% 1/16W
R676 1-218-977-11 RES-CHIP 100K 5% 1/16W
R677 1-218-977-11 RES-CHIP 100K 5% 1/16W
R679 1-218-973-11 RES-CHIP 47K 5% 1/16W
R680 1-218-965-11 RES-CHIP 10K 5% 1/16W
R681 1-218-965-11 RES-CHIP 10K 5% 1/16W
R682 1-218-965-11 RES-CHIP 10K 5% 1/16W
R683 1-218-965-11 RES-CHIP 10K 5% 1/16W
R684 1-218-990-11 SHORT 0
R685 1-218-990-11 SHORT 0
R687 1-218-990-11 SHORT 0
R688 1-218-990-11 SHORT 0
R689 1-218-965-11 RES-CHIP 10K 5% 1/16W
R690 1-218-965-11 RES-CHIP 10K 5% 1/16W
R691 1-218-977-11 RES-CHIP 100K 5% 1/16W
R692 1-218-976-11 RES-CHIP 82K 5% 1/16W
R693 1-218-977-11 RES-CHIP 100K 5% 1/16W
R694 1-218-977-11 RES-CHIP 100K 5% 1/16W
R695 1-218-965-11 RES-CHIP 10K 5% 1/16W
R696 1-218-990-11 SHORT 0
< THERMISTOR >
TH401 1-809-363-21 THERMISTOR, NTC (2125)
< VIBRATOR >
X200 1-781-834-21 VIBRATOR, CERAMIC (33.868MHz)
X202 1-781-835-21 VIBRATOR, CERAMIC (34.574MHz)
**************************************************************
A-7074-898-A SY-67 (300) BOARD, COMPLETE (SERVICE)
(CD300)
**************************************
A-7074-900-A SY-67 (200) BOARD, COMPLETE (SERVICE)
(CD200)
**************************************
(Ref.No.;5000 Series)
< CAPACITOR >
C001 1-164-880-11 CERAMIC CHIP 180PF 5% 16V
C002 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C003 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C005 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C006 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C007 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C008 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C010 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
(CD300)
C011 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
MD-083 SY-67
