6-21
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
CN705 1-766-344-21 CONNECTOR, FFC/FPC 14P
CN706 1-784-342-11 HOUSING, CONNECTOR 2P
CN707 1-784-422-11 CONNECTOR, FFC/FPC (ZIF) 33P
CN708 1-691-349-21 CONNECTOR, FFC/FPC (ZIF) 11P
CN709 1-784-421-11 CONNECTOR, FFC/FPC (ZIF) 27P
CN710 1-766-336-21 CONNECTOR, FFC/FPC 6P
CN711 1-784-342-21 HOUSING, CONNECTOR 2P
CN712 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN713 1-794-375-21 PIN, CONNECTOR 2P
< DIODE >
D001 8-719-027-76 DIODE 1SS357-TPH3
D002 8-719-027-77 DIODE MA796-TX
D003 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
D401 8-719-073-01 DIODE MA111-(K8).S0
D402 8-719-073-01 DIODE MA111-(K8).S0
D403 8-719-073-01 DIODE MA111-(K8).S0
D404 8-719-073-01 DIODE MA111-(K8).S0
D405 8-719-027-76 DIODE 1SS357-TPH3
D407 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-988-61 DIODE 1SS355TE-17
D704 8-719-016-74 DIODE 1SS352-TPH3
D713 8-719-988-61 DIODE 1SS355TE-17
D714 8-719-056-61 DIODE MAZS082008SO
< FERRITE BEAD >
FB101 1-414-228-21 FERRITE 0uH (CD300)
FB151 1-414-228-11 FERRITE 0uH
FB152 1-414-228-11 FERRITE 0uH
FB153 1-414-228-11 FERRITE 0uH
FB154 1-414-228-11 FERRITE 0uH
FB301 1-414-233-22 FERRITE 0uH
FB302 1-414-228-11 FERRITE 0uH
FB303 1-414-228-11 FERRITE 0uH
FB501 1-414-228-11 FERRITE 0uH
FB502 1-414-228-11 FERRITE 0uH
FB701 1-216-864-11 METAL CHIP 0 5% 1/16W
(Note1)
FB901 1-414-228-11 FERRITE 0uH
FB902 1-414-228-11 FERRITE 0uH
< IC >
IC001 8-759-491-22 IC MB3825APFV-G-BND-ER
IC002 6-700-080-01 IC XC62EP3102MR
IC101 8-759-831-77 IC BH2221FV-E2
IC102 8-759-524-21 IC TC74VHC174FT(EL) (CD300)
IC103 8-752-377-38 IC CXD2430N-T4 (CD300)
IC104 8-759-256-29 IC TC7S86FU(TE85R) (CD300)
IC105 8-759-256-29 IC TC7S86FU(TE85R) (CD300)
IC151 8-759-531-92 IC TC7WH04FU(TE12R)
IC152 8-759-196-97 IC TC7SH32FU-TE85R
IC153 8-759-196-97 IC TC7SH32FU-TE85R
IC154 8-759-392-77 IC TC74LCX245FT(EL)
IC155 8-759-392-77 IC TC74LCX245FT(EL)
IC156 8-759-196-96 IC TC7SH08FU-TE85R
IC157 8-759-566-06 IC TC7WH08FU(TE12R)
IC158 8-759-524-04 IC TC74VHC125FT(EL)
IC159 8-759-524-21 IC TC74VHC174FT(EL)
IC160 8-759-196-96 IC TC7SH08FU-TE85R
IC201 8-759-688-19 IC NJM2274R(TE2)
IC251 8-759-647-71 IC AK4550VT-E2
IC252 8-759-655-17 IC AN2905FHQ-EB
IC301 8-759-832-22 IC MB87J4030LGA-G-TJ-ER
IC302 6-700-079-01 IC HY57V641620HGT-PTRPV (CD200)
IC302 8-759-835-16 IC K4S561632B-TC1HT00 (CD300)
IC401 8-759-642-45 IC TL1596CPWR
IC402 6-800-401-01 IC MB89098RPFV-G-176-BN
IC403 6-700-276-01 IC NJU7285DV(TE2)
IC501 8-759-669-63 IC HD6417197BT77
IC503 Note2 IC MBM29LV160BE90TN-S119-ER
IC504 8-759-829-96 IC MB81F641642J-15PB-ER
IC505 8-759-640-87 IC BR9016RFV-E2
IC901 8-759-831-79 IC IMIC6004ATD
< COIL >
L002 1-412-056-11 INDUCTOR 4.7uH
L004 1-416-669-11 INDUCTOR 22uH
L005 1-412-056-11 INDUCTOR 4.7uH
L006 1-416-669-11 INDUCTOR 22uH
L007 1-419-881-21 INDUCTOR 47uH (CD300)
L008 1-414-392-21 INDUCTOR 1uH
L009 1-412-056-11 INDUCTOR 4.7uH
L010 1-412-056-11 INDUCTOR 4.7uH (CD300)
L011 1-412-056-11 INDUCTOR 4.7uH
L013 1-414-406-11 INDUCTOR 220uH
L014 1-412-056-11 INDUCTOR 4.7uH
L015 1-412-056-11 INDUCTOR 4.7uH
L016 1-412-056-11 INDUCTOR 4.7uH
L101 1-414-771-91 INDUCTOR 10uH
L151 1-469-525-91 INDUCTOR 10uH
L202 1-414-754-11 INDUCTOR 10uH
L251 1-469-525-91 INDUCTOR 10uH
L252 1-469-525-91 INDUCTOR 10uH
L253 1-469-525-91 INDUCTOR 10uH
L254 1-469-525-91 INDUCTOR 10uH
L301 1-469-525-91 INDUCTOR 10uH
L302 1-469-525-91 INDUCTOR 10uH
L303 1-414-756-11 INDUCTOR 47uH
L304 1-469-527-91 INDUCTOR 47uH
L305 1-469-525-91 INDUCTOR 10uH
L401 1-469-527-91 INDUCTOR 47uH
L501 1-469-525-91 INDUCTOR 10uH
L502 1-469-525-91 INDUCTOR 10uH
L503 1-469-525-91 INDUCTOR 10uH
L504 1-469-525-91 INDUCTOR 10uH
L505 1-412-951-11 INDUCTOR 10uH
L901 1-414-757-11 INDUCTOR 100uH (CD200)
L901 1-469-525-91 INDUCTOR 10uH (CD300)
< TRANSISTOR >
Q001 8-729-033-14 TRANSISTOR FP107-TL
Q002 8-729-804-41 TRANSISTOR 2SB1122-ST-TD
Q003 8-729-033-14 TRANSISTOR FP107-TL (CD300)
Q004 8-729-033-14 TRANSISTOR FP107-TL
Q005 8-729-033-14 TRANSISTOR FP107-TL
SY-67
Note2: Part number is not fixed yet.
It will be notified by Technical News when it is fixed.
Note1: Metal chip is mounted to the location where FB701 is
printed.
