Sony MVC-FD73

6-6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PK-46(C)FU-134
FC-69
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
R874 1-216-841-11 METAL CHIP 47K 5% 1/16W
R875 1-216-841-11 METAL CHIP 47K 5% 1/16W
R876 1-216-841-11 METAL CHIP 47K 5% 1/16W
R877 1-216-841-11 METAL CHIP 47K 5% 1/16W
R878 1-216-841-11 METAL CHIP 47K 5% 1/16W
R879 1-216-841-11 METAL CHIP 47K 5% 1/16W
R880 1-216-841-11 METAL CHIP 47K 5% 1/16W
R904 1-216-864-11 METAL CHIP 0 5% 1/16W
R909 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R910 1-216-850-11 METAL CHIP 270K 5% 1/16W
R912 1-216-864-11 METAL CHIP 0 5% 1/16W
R913 1-216-864-11 METAL CHIP 0 5% 1/16W
R914 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R915 1-218-879-11 RES,CHIP 22K 0.50% 1/16W
R916 1-218-852-11 RES,CHIP 1.6K 0.50% 1/16W
R917 1-218-863-11 RES,CHIP 4.7K 0.50% 1/16W
R918 1-216-840-11 METAL CHIP 39K 5% 1/16W
R919 1-216-838-11 METAL CHIP 27K 5% 1/16W
R920 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R921 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R922 1-216-864-11 METAL CHIP 0 5% 1/16W
R924 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R925 1-218-837-11 RES,CHIP 390 0.50% 1/16W
R926 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R927 1-216-847-11 METAL CHIP 150K 5% 1/16W
R928 1-216-833-91 RES,CHIP 10K 5% 1/16W
R929 1-216-864-11 METAL CHIP 0 5% 1/16W
R930 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R931 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R932 1-216-864-11 METAL CHIP 0 5% 1/16W
R933 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R934 1-216-841-11 METAL CHIP 47K 5% 1/16W
R935 1-216-843-11 METAL CHIP 68K 5% 1/16W
R936 1-216-821-11 METAL CHIP 1K 5% 1/16W
R937 1-216-821-11 METAL CHIP 1K 5% 1/16W
R938 1-216-864-11 METAL CHIP 0 5% 1/16W
R940 1-216-864-11 METAL CHIP 0 5% 1/16W
R941 1-218-875-11 RES,CHIP 15K 0.50% 1/16W
R942 1-218-863-11 RES,CHIP 4.7K 0.50% 1/16W
R943 1-216-833-91 RES,CHIP 10K 5% 1/16W
R946 1-216-813-11 METAL CHIP 220 5% 1/16W
R947 1-216-819-11 METAL CHIP 680 5% 1/16W
R948 1-216-817-11 METAL CHIP 470 5% 1/16W
R949 1-216-817-11 METAL CHIP 470 5% 1/16W
R951 1-216-864-11 METAL CHIP 0 5% 1/16W
R952 1-216-845-11 METAL CHIP 100K 5% 1/16W
R953 1-216-845-11 METAL CHIP 100K 5% 1/16W
R954 1-216-821-11 METAL CHIP 1K 5% 1/16W
R956 1-216-845-11 METAL CHIP 100K 5% 1/16W
R957 1-216-841-11 METAL CHIP 47K 5% 1/16W
R958 1-216-837-11 METAL CHIP 22K 5% 1/16W
R960 1-218-883-11 RES,CHIP 33K 0.50% 1/16W
R961 1-218-877-11 RES,CHIP 18K 0.50% 1/16W
R962 1-218-895-11 RES,CHIP 100K 0.50% 1/16W
R963 1-218-893-11 RES,CHIP 82K 0.50% 1/16W
R964 1-218-883-11 RES,CHIP 33K 0.50% 1/16W
R965 1-216-835-11 METAL CHIP 15K 5% 1/16W
R966 1-216-845-11 METAL CHIP 100K 5% 1/16W
R967 1-216-841-11 METAL CHIP 47K 5% 1/16W
R968 1-216-845-11 METAL CHIP 100K 5% 1/16W
R969 1-216-845-11 METAL CHIP 100K 5% 1/16W
R970 1-216-845-11 METAL CHIP 100K 5% 1/16W
R971 1-216-841-11 METAL CHIP 47K 5% 1/16W
R972 1-216-845-11 METAL CHIP 100K 5% 1/16W
R973 1-216-845-11 METAL CHIP 100K 5% 1/16W
R974 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R975 1-216-833-91 RES,CHIP 10K 5% 1/16W
R976 1-218-877-11 RES,CHIP 18K 0.50% 1/16W
R977 1-218-852-11 RES,CHIP 1.6K 5% 1/16W
R978 1-218-897-11 RES,CHIP 120K 0.50% 1/16W
R979 1-218-882-11 RES,CHIP 30K 0.50% 1/16W
R980 1-218-871-11 RES,CHIP 10K 0.50% 1/16W
R981 1-218-889-11 RES,CHIP 56K 0.50% 1/16W
R986 1-216-841-11 METAL CHIP 47K 5% 1/16W
< SENSOR >
SE801 1-801-868-41 SENSOR, SHOCK
< TRANSFORMER >
! T901 1-429-565-21 TRANSFORMER, CONVERTER
< VIBRATOR >
X101 1-767-923-11 VIBRATOR, CRYSTAL (36MHz)
X701 1-767-450-11 VIBRATOR, CERAMIC (20MHz)
X702 1-760-458-21 VIBRATOR, CRYSTAL (32.768kHz)
X802 1-767-921-11 VIBRATOR, CERAMIC (15MHz)
X803 1-767-922-11 VIBRATOR, CERAMIC (16MHz)
**************************************************************
A-7073-965-A FU-134 BOARD, COMPLETE
*********************
(Ref. No. 1,000 Series)
< CONNECTOR >
* CN501 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN502 1-770-625-21 PIN, CONNECTOR 8P
< FUSE >
! F501 1-576-286- FUSE, MICRO (1.4A)
! F502 1-576-286- FUSE, MICRO (1.4A)
! F503 1-576-286- FUSE, MICRO (1.4A)
! F504 1-576-286- FUSE, MICRO (1.4A)
**************************************************************
A-709-435-1A PK-46(C) BOARD, COMPLETE (SERVICE)
*********************************
(Ref. No. 2,000 Series)
< BATTERY HOLDER >
BH701 1-550-104-32 HOLDER, BATTERY
: Added board.
