Sony MVC-FD73

6-7
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
PK-46(C)
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
< BUZZER >
BZ701 1-529-107-11 BUZZER, PIEZOELECTRIC
< CAPACITOR >
C601 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C602 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C604 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C606 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C702 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C703 1-165-320-11 CERAMIC CHIP 0.47uF 10% 16V
C704 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C705 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C801 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C802 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C807 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C808 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C811 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C812 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C813 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C814 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C851 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C853 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C854 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C855 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C856 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C857 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C858 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C859 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C861 1-104-911-11 TANTAL. CHIP 33uF 20% 10V
C862 1-164-346-11 CERAMIC CHIP 1uF 16V
C863 1-164-661-11 CERAMIC CHIP 0.018uF 10% 50V
C865 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
! C866 1-113-521-91 CERAMIC CHIP 12PF 10% 3KV
C867 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C901 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C902 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C903 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C904 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C905 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C906 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C908 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C909 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C911 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C913 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C915 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C918 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C919 1-107-689-21 TANTAL. CHIP 1uF 20% 35V
C920 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C921 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C926 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN601 1-764-526-11 CONNECTOR, FFC/FPC 18P
* CN602 1-750-075-11 CONNECTOR, FFC/FPC 10P
CN603 1-778-598-21 CONNECTOR, BOARD TO BOARD 60P
CN802 1-764-526-11 CONNECTOR, FFC/FPC 18P
CN851 1-573-929-11 CONNECTOR, FFC/FPC (ZIF) 20P
CN901 1-691-388-11 CONNECTOR, FFC/FPC (ZIF) 24P
< DIODE >
D701 8-719-061-82 DIODE TLSU1002(TPX1,SONY)(ACCESS)
D702 8-719-061-81 DIODE TLYU1002(TPX1,SONY)
(FLASH CHARGE)
D852 8-719-073-01 DIODE MA111-(K8).S0
D853 8-719-073-01 DIODE MA111-(K8).S0
D854 8-719-073-01 DIODE MA111-(K8).S0
D903 8-713-102-80 DIODE 1T369-01-T8A
D904 8-719-976-96 DIODE MA8047-H-TX
< IC >
IC601 8-759-535-05 IC BH9530KS2
IC801 8-759-530-19 IC MB40D001PFV-G-BND-ER
IC802 8-759-539-27 IC IR3Y37A4
IC851 8-759-521-35 IC TL5001CDR
IC852 8-759-075-70 IC TA75S393F-TE85R
IC901 8-759-530-20 IC CM7017L3-T4
IC902 8-759-327-01 IC NJM062V(TE2)
IC903 8-759-523-03 IC TC74HC4066AFT(EL)
< COIL >
L601 1-414-394-11 INDUCTOR 2.2uH
L701 1-216-296-91 SHORT 0
L801 1-414-402-11 INDUCTOR 47uH
L802 1-414-078-11 INDUCTOR 10uH
L851 1-414-396-21 INDUCTOR 4.7uH
L852 1-424-674-11 INDUCTOR 22uH
L853 1-409-536-41 INDUCTOR 150uH
L901 1-414-754-11 INDUCTOR 10uH
L902 1-414-754-11 INDUCTOR 10uH
L903 1-412-951-11 INDUCTOR 10uH
L904 1-414-754-11 INDUCTOR 10uH
L905 1-412-953-11 INDUCTOR 15uH
< TRANSISTOR >
Q701 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q702 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q851 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q852 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q853 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q854 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q855 8-729-042-29 TRANSISTOR RN1104F(TPL3)
Q856 8-729-823-84 TRANSISTOR FP102-TL
Q857 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q858 8-729-037-52 TRANSISTOR 2SC4738F-Y/GR(TPL3)
Q859 8-729-042-29 TRANSISTOR RN1104F(TPL3)
