Sony NW-E002F - IC Pin Function Description MAIN BOARD IC101 CXD5090-003 GG

20
NW-E002F/E003F/E005F
• IC Pin Function Description
MAIN BOARD IC101 CXD5090-003GG
(SYSTEM CONTROLLER, NAND FLASH INTERFACE, USB INTERFACE, A/D, D/A CONVERTER, SERIAL INTERFACE)
Pin No. Pin Name I/O Description
1NAD0/GPIOC0 I Data signal
2NAD1/GPIOC1 I Data signal
3NAD2/GPIOC2 I Data signal
4NAD3/GPIOC3 I Data signal
5NAD4/GPIOC4 I Data signal
6NAD5/GPIOC5 I Data signal
7NAD6/GPIOC6 I Data signal
8NAD7/GPIOC7 I Data signal
9 NCLE/GPIOC8 O Command latch enable signal to NAND FLASH ROM
10 NALE/GPIOC9 O Address latch enable signal to NAND FLASH ROM
11 NCE0/GPIOC10 O Chip enable signal to NAND FLASH ROM
12 NCE1/GPIOC11 O Chip enable signal (Not used)
13 NCE2/GPIOC12 O Chip enable signal (Connected to ground terminal)
14 NCE3/GPIOC13 O Chip enable signal (Connected to ground terminal)
15 NRE/GPIOC14 O Read signal to NAND FLASH ROM
16 NWE/GPIOC15 O Write signal to NAND FLASH ROM
17 NWP/GPIOC16 O Write protection signal to NAND FLASH ROM
18 NRB0/GPIOC17 O Read/Busy signal to NAND FLASH ROM
19 NRB1/GPIOC18 O Read/Busy signal (Not used)
20 NRB2/GPIOC19 O Read/Busy signal (Connected to +2.8V)
21 NRB3/GPIOC20 O Read/Busy signal (Connected to +2.8V)
22 DVS — Ground terminal
23 DVDIO2 — Power supply terminal
24 DVDIO2 — Power supply terminal
25 DVS — Ground terminal
26 DVDK2 — Power supply terminal
27 DVS — Ground terminal
28 CRST2 I Reset signal (Pull down)
29 RST2OUT O Reset signal output for Power Control IC
30 RST2VDD — Power supply terminal
31 T_ADINL — For TEST (Connected to ground terminal)
32 HPVDD — Power supply terminal
33 HPOUTL O Headphone Lch signal output
34 PVDD — Power supply terminal
35 PGND — Ground terminal
36 HPOUTR O Headphone Rch signal output
37 HPGND — Ground terminal
38 GPION0/INT8 I Wake up signal input
39 GPION1/INT9 I HOLD key signal input
40 GPION2/INT10 I Function key signal input
41 GPION3/INT11 I Function key signal input
42 TDI I JTAG data input (Not used)
43 TMS I JTAG test mode control signal input (Not used)
44 TCK I JTAG clock signal input (Not used)
45 TDO O JTAG clock signal output (Not used)
46 TRST I JTAG reset input
47 TEST I Boot control
