NW-E002F/E003F/E005F
Pin No. Pin Name I/O Description
48 EVA I EVA/FLASH modes selector (Not used)
49 TREQA I JTAG request signal input (Connected to ground terminal)
50 TACK O JTAG request signal input (Not used)
51 SCL/GPIOK0 I/O Serial clock (Connected to +2.8V)
52 SDA/GPIOK1 I/O Serial data (Connected to ground terminal)
53 EC0/INT6/GPIOL0 I Model confide (Connected to ground terminal)
54 T1/GPIOL1 — Connected to ground terminal
55 EC2/INT7/GPIOL2 — Connected to ground terminal
56 T3/GPIOL3 O NAND Power control
57 BEEP/GPIOL4 O BEEP output
58
PWM/SUSPEND/GPIOL5
— Connected to ground terminal
59 DVS — Ground terminal
60 DVDIO2 — Power supply terminal
61 DVDIO2 — Power supply terminal
62 DVS — Ground terminal
63 DVDK2 — Power supply terminal
64 DVS — Ground terminal
65 BEEPEN I BEEP input
66 HPINL I Audio signal (L) input
67 HPLININL I Tuner signal (L) input
68 HPINR I Audio signal (R) input
69 HPLININR I Tuner signal (R) input
70 AVDLPF — LPF power supply terminal
71 VREFL O HP Amp Reference (L)
72 AOUTL O HP out (L)
73 AOUTR O HP out (R)
74 VREFR O HP Out Reference (R)
75 AVSLPF I Connected to ground terminal
76 AVDADC — Power supply terminal
77 AN0 I Function key signal input
78 AN1 I ADC analogue signal (Connected to ground terminal)
79 AN2 I ADC analogue signal (Connected to ground terminal)
80 AN3 I ADC analogue signal (Connected to ground terminal)
81 AN4 I ADC analogue signal (Connected to ground terminal)
82 AN5 I ADC analogue signal (Connected to ground terminal)
83 AN6 I ADC analogue signal (Connected to ground terminal)
84 AN7 I ADC analogue signal
85 AVSADC — Ground terminal
86 NC — Not used
87 INT1/GPIOF0 I RTC control
88
DREQ/
IRTC control
INT2/GPIOF1
89
DACK/
IBattery voltage
INT3/GPIOF2
90 INT4/GPIOF3 O OEL control
91 INT5/GPIOF4 O OEL control
92 DVS — Ground terminal
93 DVDIO2 — Power supply terminal
94 DVDK2 — Power supply terminal
