25
NW-E002F/E003F/E005F
Pin No. Pin Name I/O Description
242 DVS — Ground terminal
243 DVDIO2 — Power supply terminal
244 DVDIO2 — Power supply terminal
245 DVS — Ground terminal
246 INTR — Not used
247 RTCVSB — Power supply terminal (RTC)
248 OSCIN I Oscillator connection terminal for RTC (32.768kHz)
249 OSCOUT O Oscillator connection terminal for RTC (32.768kHz) (Not used)
250 CLK32KOUT O Clock output for RTC (Not used)
251 DSUBGND — Ground terminal
252 DRAIN O NAND Power output
253 DVS — Ground terminal
254 DVDIO0 — Power supply terminal
255 DVDK0 — Power supply terminal
256 DVS — Ground terminal
257 SOURCE I NAND Power input
258 GATE I NAND Power control
259 CRST1A I Reset signal input
260 CRST1B I Reset signal input (Not used)
261 RST1VDD — Power supply terminal
262 RST1AOUT O Reset signal output
263 RST1BOUT O Reset signal output (Not used)
264 RSTGND — Ground terminal
265 RST O Reset signal output for FLASH ROM and SRAM
266 NC — Not used
267 NC — Not used
268 NC — Not used
269 NC — Not used
270 NC — Not used
271 NC — Not used
272 NC — Not used
273 NC — Not used
