24
NW-E002F/E003F/E005F
Pin No. Pin Name I/O Description
193 DVDK2 — Power supply terminal
194 DVS — Ground terminal
195 A17 O Address signal to FLASH ROM, SRAM
196 A18 O Address signal to FLASH ROM, SRAM
197 A19 O Address signal to FLASH ROM, SRAM
198 A20 O Address signal to FLASH ROM, SRAM
199 A21 O Address signal to FLASH ROM, SRAM
200 A22 O Address signal (Not used)
201 A23/GPIOA1 O Address signal (Connected to ground terminal)
202 A24/GPIOA2 I Model confide (Connected to ground terminal)
203 A25/GPIOA3 I Model confide (Connected to ground terminal)
204 D0/GPIOA4 I/O Data signal to FLASH ROM, SRAM
205 D1/GPIOA5 I/O Data signal to FLASH ROM, SRAM
206 D2/GPIOA6 I/O Data signal to FLASH ROM, SRAM
207 D3/GPIOA7 I/O Data signal to FLASH ROM, SRAM
208 D4/GPIOA8 I/O Data signal to FLASH ROM, SRAM
209 D5/GPIOA9 I/O Data signal to FLASH ROM, SRAM
210 D6/GPIOA10 I/O Data signal to FLASH ROM, SRAM
211 D7/GPIOA11 I/O Data signal to FLASH ROM, SRAM
212 DVS — Ground terminal
213 DVDIO2 — Power supply terminal
214 DVDIO2 — Power supply terminal
215 DVS — Ground terminal
216 DVDK2 — Power supply terminal
217 DVS — Ground terminal
218 RTCVDD — Power supply terminal
219 RTCREGO O RTC Power output
220 RTCVREF — Reference voltage (Not used)
221 RTCGND — Ground terminal
222 D8/GPIOA12 I/O Data signal to FLASH ROM, SRAM
223 D9/GPIOA13 I/O Data signal to FLASH ROM, SRAM
224 D10/GPIOA14 I/O Data signal to FLASH ROM, SRAM
225 D11/GPIOA15 I/O Data signal to FLASH ROM, SRAM
226 D12/GPIOA16 I/O Data signal to FLASH ROM, SRAM
227 D13/GPIOA17 I/O Data signal to FLASH ROM, SRAM
228 D14/GPIOA18 I/O Data signal to FLASH ROM, SRAM
229 D15/GPIOA19 I/O Data signal to FLASH ROM, SRAM
230 WAIT/GPIOA20 O Wait signal to FLASH ROM, SRAM
231 CS0/GPIOA21 O Chip select to FLASH ROM, SRAM
232 CS1/GPIOA22 O Chip select to FLASH ROM, SRAM
233 CS2/GPIOA23 O Chip select to FLASH ROM, SRAM
234 CS3/GPIOA24 O Chip select to FLASH ROM, SRAM (Connected to ground terminal)
235 CS4/GPIOA25 O Chip select to FLASH ROM, SRAM
236 RE/GPIOA26 O Read signal to FLASH ROM, SRAM
237 WE/GPIOA27 O Write Signal to FLASH ROM, SRAM
238 LB/GPIOA28 O Lower Byte access strobe signal to FLASH ROM, SRAM
239 UB/GPIOA29 O Upper Byte access strobe signal to FLASH ROM, SRAM
240 DVDK2 — Power supply terminal
241 DVS — Ground terminal
