NW-E002F/E003F/E005F
Pin No. Pin Name I/O Description
144 DVDK1 — Power supply terminal
145 DVS — Ground terminal
146 FS256 O PCM FS256 (Not used)
147 LRCK/WS I PCM LRCK (Not used)
148 BCK/SCK I PCM BCLK (Not used)
149 ADDT/SDI/GPIOM0 I PCM ADOUT (Not used)
150 DADT/SDO/GPIOM1 O Not used
151 MUTFGL/GPIOM2 O Not used
152 MUTFGR/GPIOM3 O Model confide (Connected to ground terminal)
153 DVS — Ground terminal
154 DVDIO2 — Power supply terminal
155 DVDIO2 — Power supply terminal
156 DVS — Ground terminal
157 DVDK2 — Power supply terminal
158 DVS — Ground terminal
159 NBOOT I Boot mode select (Not used)
160 A0/GPIOA0 O Address signal (Not used)
161 A1 O Address signal to FLASH ROM, SRAM
162 A2 O Address signal to FLASH ROM, SRAM
163 A3 O Address signal to FLASH ROM, SRAM
164 A4 O Address signal to FLASH ROM, SRAM
165 A5 O Address signal to FLASH ROM, SRAM
166 A6 O Address signal to FLASH ROM, SRAM
167 A7 O Address signal to FLASH ROM, SRAM
168 A8 O Address signal to FLASH ROM, SRAM
169 A9 O Address signal to FLASH ROM, SRAM
170 A10 O Address signal to FLASH ROM, SRAM
171 A11 O Address signal to FLASH ROM, SRAM
172 A12 O Address signal to FLASH ROM, SRAM
173 A13 O Address signal to FLASH ROM, SRAM
174 A14 O Address signal to FLASH ROM, SRAM
175 A15 O Address signal to FLASH ROM, SRAM
176 A16 O Address signal to FLASH ROM, SRAM
177 AGND — Ground terminal
178 ADVREF — Reference voltage
179 AVDD — Power supply terminal
180 SUBGND — for TEST (Connected to ground terminal)
181 MICOUTL O MIC signal output (Not used)
182 MICOUTR O MIC signal output (Not used)
183 MICINL I Tuner signal input
184 MLININL I MIC signal input (Not used)
185 MICVREF — Reference voltage
186 MICINR I Tuner signal input
187 MLININL I MIC signal input (Not used)
188 T_ADINR — For TEST (Connected to ground terminal)
189 DVS — Ground terminal
190 DVDIO2 — Power supply terminal
191 DVDIO2 — Power supply terminal
192 DVS — Ground terminal
To Next Page
