Sony NW-E403 - Printed Wiring Board - MAIN Board (Side A)

1414
NW-E403/E405/E407
NW-E403/E405/E407
4-2. PRINTED WIRING BOARD – MAIN BOARD (SIDE A) –
:Uses unleaded solder.
• Semiconductor
Location
Ref. No. Location
D801 D-5
IC401 C-4
IC501 C-9
IC503 B-4
IC505 D-9
IC506 D-9
Q505 B-9
Q801 D-6
IC401
IC503
IC501
IC506IC505
A
SW BOARD
CN702
(Page 21)
1
2
BT901
RECHARGEABLE
BATTERY
Li-ion Mn
1PC, 4.0V
LCD901
LIQUID CRYSTAL
DISPLAY
MAIN BOARD (SIDE A)
1-866-679-
(11)
11
R3019
R3020
R3011
1
2
39
38
1
2
1
3
5
4
1
1
10
20
11
3
5
4
1
1
23
4
3
5
4
