NW-E403/E405/E407
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• Accessories are given in the last of this parts
list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
X-2059-981-1 MAIN BOARD, COMPLETE (E403:AEP)
X-2059-982-1 MAIN BOARD, COMPLETE
(E403:US,CND,KR,JE)
X-2059-984-1 MAIN BOARD, COMPLETE (E405:AEP)
X-2059-985-1 MAIN BOARD, COMPLETE
(E405:US,CND,KR,AUS,JE)
X-2059-987-1 MAIN BOARD, COMPLETE (E407:AEP)
X-2059-988-1 MAIN BOARD, COMPLETE
(E407:US,CND,KR,AUS,JE)
*********************
< CAPACITOR >
C101 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C102 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C103 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C111 1-137-707-11 TANTAL. CHIP 220uF 20% 4V
C201 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C202 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C203 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C211 1-137-707-11 TANTAL. CHIP 220uF 20% 4V
C302 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C309 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C310 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C311 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C312 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C313 1-165-887-91 CERAMIC CHIP 0.22uF 10% 6.3V
C314 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C315 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C316 1-100-415-11 CERAMIC CHIP 0.47uF 10% 6.3V
C317 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C318 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C319 1-165-884-91 CERAMIC CHIP 2.2uF 10% 6.3V
C321 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C400 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C401 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-135-869-91 TANTAL. CHIP 4.7uF 20% 6.3V
C403 1-135-869-91 TANTAL. CHIP 4.7uF 20% 6.3V
C404 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C405 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C406 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C407 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C408 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-125-926-91 TANTAL. CHIP 4.7uF 20% 6.3V
C411 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C414 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C415 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C416 1-164-850-11 CERAMIC CHIP 10PF 0.5PF 50V
C417 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C418 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C419 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C420 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C421 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C422 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C423 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C425 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C450 1-100-504-91 CERAMIC CHIP 0.1uF 20% 6.3V
C451 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C462 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C501 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C502 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C503 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C504 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C505 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C506 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C507 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C508 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C510 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C511 1-100-507-91 CERAMIC CHIP 4.7uF 20% 6.3V
C512 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C514 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C516 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C517 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C518 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C519 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C520 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C521 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C522 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C525 1-100-878-91 TANTAL. CHIP 47uF 20% 10V
C526 1-100-878-91 TANTAL. CHIP 47uF 20% 10V
C701 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C703 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C705 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C801 1-100-735-91 CERAMIC CHIP 10uF 20% 4V
C805 1-112-537-91 TANTAL. CHIP 1uF 20% 35V
C806 1-100-506-91 CERAMIC CHIP 1uF 20% 6.3V
C807 1-100-670-11 CERAMIC CHIP 4.7uF 20% 16V
C808 1-100-352-91 CERAMIC CHIP 1uF 20% 16V
C809 1-112-537-91 TANTAL. CHIP 1uF 20% 35V
C810 1-164-874-11 CERAMIC CHIP 100PF 5% 50V
C811 1-112-537-91 TANTAL. CHIP 1uF 20% 35V
C812 1-112-537-91 TANTAL. CHIP 1uF 20% 35V
< CONNECTOR >
CN400 1-818-513-21 CONNECTOR (SQUARE TYPE) (USB) 5P
CN501 1-770-619-11 PIN, CONNECTOR 2P
CN701 1-818-284-11 CONNECTOR, BOARD TO BOARD 10P
CN801 1-818-600-11 CONNECTOR, FPC (ZIF) 39P
When indicating parts by reference number,
please include the board name.
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
JE : Tourist model
CND : Canadian model
AUS: Australian model
KR : Korean model
MAIN
Ver. 1.3
To Next Page
