27
NW-E403/E405/E407
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< DIODE >
D301 8-719-059-53 DIODE MA3J14700LSO
D801 6-500-460-01 DIODE RSX101M-30TR
< FERRITE BEAD >
FB111 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB211 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB301 1-414-813-11 FERRITE, EMI (SMD) (2012)
< IC >
IC301 6-707-074-01 IC TB2173FTG
IC400 8-753-234-35 IC CXR704060-202GA
IC401 8-759-641-91 IC RV5C348A-E2
✩ IC450 - - - - - - - - - - IC S99-50082
IC501 6-708-160-01 IC SN412005RHLR
IC503 6-708-158-01 IC MM3032JULE
IC505 6-703-802-01 IC TPS62200DBVR
IC506 6-703-802-01 IC TPS62200DBVR
IC507 6-703-175-01 IC PST3629UL
* IC508 6-705-243-01 IC PST3624UL
IC509 6-708-145-01 IC XC6219B232MR
IC1461 6-707-829-01 IC K04SONY99 (E407)
IC1461 6-707-830-01 IC K04SONY95 (E405)
IC1461 6-708-162-01 IC K05SONY03 (E403)
< COIL >
L501 1-457-082-21 INDUCTOR 10uH
L502 1-457-082-21 INDUCTOR 10uH
L801 1-457-081-21 COIL, CHOKE 10uH
< TRANSISTOR >
Q501 6-551-346-01 TRANSISTOR 2SK3541T2L
Q502 8-729-041-23 TRANSISTOR NDS356AP
Q503 6-551-346-01 TRANSISTOR 2SK3541T2L
Q504 6-550-747-01 TRANSISTOR 3LP01S-K-TL-E
Q505 6-551-346-01 TRANSISTOR 2SK3541T2L
Q506 6-551-346-01 TRANSISTOR 2SK3541T2L
Q507 6-550-747-01 TRANSISTOR 3LP01S-K-TL-E
Q801 6-551-354-01 TRANSISTOR MCH3443-TL-E
< RESISTOR >
R101 1-218-969-11 RES-CHIP 22K 5% 1/16W
R102 1-218-965-11 RES-CHIP 10K 5% 1/16W
R103 1-218-949-11 RES-CHIP 470 5% 1/16W
R105 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R106 1-218-973-11 RES-CHIP 47K 5% 1/16W
R201 1-218-969-11 RES-CHIP 22K 5% 1/16W
R202 1-218-965-11 RES-CHIP 10K 5% 1/16W
R203 1-218-949-11 RES-CHIP 470 5% 1/16W
R205 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R206 1-218-973-11 RES-CHIP 47K 5% 1/16W
R301 1-218-990-11 SHORT CHIP 0
R308 1-218-990-11 SHORT CHIP 0
R310 1-218-977-11 RES-CHIP 100K 5% 1/16W
R312 1-218-977-11 RES-CHIP 100K 5% 1/16W
R314 1-218-990-11 SHORT CHIP 0
R319 1-218-977-11 RES-CHIP 100K 5% 1/16W
R401 1-218-990-11 SHORT CHIP 0
R402 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R404 1-218-945-11 RES-CHIP 220 5% 1/16W
R405 1-218-990-11 SHORT CHIP 0
R406 1-218-933-11 RES-CHIP 22 5% 1/16W
R407 1-218-933-11 RES-CHIP 22 5% 1/16W
R408 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R409 1-218-933-11 RES-CHIP 22 5% 1/16W
R410 1-218-941-81 RES-CHIP 100 5% 1/16W
R411 1-218-989-11 RES-CHIP 1M 5% 1/16W
R412 1-218-945-11 RES-CHIP 220 5% 1/16W
R414 1-218-965-11 RES-CHIP 10K 5% 1/16W
R415 1-218-977-11 RES-CHIP 100K 5% 1/16W
R416 1-218-965-11 RES-CHIP 10K 5% 1/16W
R418 1-218-945-11 RES-CHIP 220 5% 1/16W
R419 1-218-965-11 RES-CHIP 10K 5% 1/16W
R420 1-218-965-11 RES-CHIP 10K 5% 1/16W
R421 1-218-977-11 RES-CHIP 100K 5% 1/16W
R422 1-218-965-11 RES-CHIP 10K 5% 1/16W
R423 1-218-985-11 RES-CHIP 470K 5% 1/16W
R424 1-218-965-11 RES-CHIP 10K 5% 1/16W
R426 1-218-965-11 RES-CHIP 10K 5% 1/16W
R427 1-218-945-11 RES-CHIP 220 5% 1/16W
R429 1-218-973-11 RES-CHIP 47K 5% 1/16W
R430 1-218-945-11 RES-CHIP 220 5% 1/16W
R431 1-218-945-11 RES-CHIP 220 5% 1/16W
R450 1-218-990-11 SHORT CHIP 0
R451 1-218-977-11 RES-CHIP 100K 5% 1/16W
R452 1-218-977-11 RES-CHIP 100K 5% 1/16W
R453 1-218-985-11 RES-CHIP 470K 5% 1/16W
R454 1-218-990-11 SHORT CHIP 0
R455 1-218-990-11 SHORT CHIP 0
R461 1-218-977-11 RES-CHIP 100K 5% 1/16W
R467 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R501 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R502 1-218-977-11 RES-CHIP 100K 5% 1/16W
R503 1-218-977-11 RES-CHIP 100K 5% 1/16W
R504 1-218-985-11 RES-CHIP 470K 5% 1/16W
R505 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R506 1-218-989-11 METAL CHIP 1M 0.5% 1/16W
R507 1-218-985-11 RES-CHIP 470K 5% 1/16W
R508 1-218-990-11 SHORT CHIP 0
R509 1-218-985-11 RES-CHIP 470K 5% 1/16W
R510 1-218-990-11 SHORT CHIP 0
R511 1-218-941-81 RES-CHIP 100 5% 1/16W
R512 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R513 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R514 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R515 1-208-935-11 METAL CHIP 100K 0.5% 1/16W
R516 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R517 1-218-965-11 RES-CHIP 10K 5% 1/16W
R518 1-218-985-11 RES-CHIP 470K 5% 1/16W
R519 1-218-985-11 RES-CHIP 470K 5% 1/16W
R520 1-218-990-11 SHORT CHIP 0
R521 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R522 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R523 1-218-985-11 RES-CHIP 470K 5% 1/16W
R524 1-218-985-11 RES-CHIP 470K 5% 1/16W
MAIN
Ver. 1.5
✩ IC450 on MAIN board cannot be replaced individually.
Replace it with “MAIN BOARD,COMPLETE” for service.
