28
NW-E403/E405/E407
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R525 1-218-977-11 RES-CHIP 100K 5% 1/16W
R526 1-218-965-11 RES-CHIP 10K 5% 1/16W
R528 1-218-965-11 RES-CHIP 10K 5% 1/16W
R529 1-218-965-11 RES-CHIP 10K 5% 1/16W
R530 1-218-985-11 RES-CHIP 470K 5% 1/16W
R531 1-218-965-11 RES-CHIP 10K 5% 1/16W
R533 1-218-985-11 RES-CHIP 470K 5% 1/16W
R534 1-218-973-11 RES-CHIP 47K 5% 1/16W
R535 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R536 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R537 1-218-990-11 SHORT CHIP 0
R538 1-218-990-11 SHORT CHIP 0
R539 1-218-990-11 SHORT CHIP 0
R540 1-218-990-11 SHORT CHIP 0
R701 1-218-969-11 RES-CHIP 22K 5% 1/16W
R702 1-218-965-11 RES-CHIP 10K 5% 1/16W
R704 1-218-965-11 RES-CHIP 10K 5% 1/16W
R705 1-218-985-11 RES-CHIP 470K 5% 1/16W
R707 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R709 1-218-965-11 RES-CHIP 10K 5% 1/16W
R711 1-218-965-11 RES-CHIP 10K 5% 1/16W
R713 1-218-949-11 RES-CHIP 470 5% 1/16W
R714 1-218-969-11 RES-CHIP 22K 5% 1/16W
R715 1-218-965-11 RES-CHIP 10K 5% 1/16W
R716 1-218-965-11 RES-CHIP 10K 5% 1/16W
R717 1-218-965-11 RES-CHIP 10K 5% 1/16W
R718 1-218-969-11 RES-CHIP 22K 5% 1/16W
R720 1-218-990-11 SHORT CHIP 0
R721 1-218-965-11 RES-CHIP 10K 5% 1/16W
R722 1-218-985-11 RES-CHIP 470K 5% 1/16W
R723 1-218-985-11 RES-CHIP 470K 5% 1/16W
R724 1-218-965-11 RES-CHIP 10K 5% 1/16W
R725 1-218-985-11 RES-CHIP 470K 5% 1/16W
R732 1-218-990-11 SHORT CHIP 0
R733 1-218-990-11 SHORT CHIP 0
R735 1-218-990-11 SHORT CHIP 0
R801 1-244-161-81 RES-CHIP 2.2 5% 1/16W
R802 1-244-161-81 RES-CHIP 2.2 5% 1/16W
R803 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R804 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R805 1-218-990-11 SHORT CHIP 0
R806 1-218-990-11 SHORT CHIP 0
R807 1-208-943-11 METAL CHIP 220K 0.5% 1/16W
R808 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R809 1-218-977-11 RES-CHIP 100K 5% 1/16W
R810 1-218-985-11 RES-CHIP 470K 5% 1/16W
R811 1-218-990-11 SHORT CHIP 0
R812 1-218-990-11 SHORT CHIP 0
R1464 1-218-990-11 SHORT CHIP 0 (E403, E405)
R1465 1-218-990-11 SHORT CHIP 0 (E407)
R1466 1-218-990-11 SHORT CHIP 0 (E407)
R3011 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R3019 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R3020 1-218-985-11 METAL CHIP 470K 0.5% 1/16W
R3729 1-218-990-11 SHORT CHIP 0
< SWITCH >
S702 1-786-860-11 SWITCH, TACTILE (VOL +)
S703 1-786-860-11 SWITCH, TACTILE (VOL –)
S705 1-786-453-21 SWITCH, TACTILE (REPEAT SOUND)
S710 1-786-453-21 SWITCH, TACTILE (RESET)
< THERMISTOR >
TH501 1-804-949-11 THERMISTOR, NTC (SMD)
< VARISTOR >
VDR101 1-803-742-21 VARISTOR, CHIP
VDR201 1-803-742-21 VARISTOR, CHIP
VDR401 1-803-742-21 VARISTOR, CHIP
VDR402 1-805-216-21 VARISTOR, CHIP
VDR403 1-805-216-21 VARISTOR, CHIP
VDR405 1-805-216-21 VARISTOR, CHIP
VDR406 1-805-216-21 VARISTOR, CHIP
< VIBRATOR >
X400 1-795-891-21 VIBRATOR, CERAMIC 22.579MHz
X401 1-795-792-21 VIBRATOR, CRYSTAL 16MHz
X402 1-795-794-21 VIBRATOR, CRYSTAL 32.768KHz
************************************************************
A-1114-321-A SW BOARD, COMPLETE
*******************
< CONNECTOR >
CN702 1-815-874-21 CONNECTOR, BOARD TO BOARD 10P
< RESISTOR >
R700 1-218-973-11 RES-CHIP 47K 5% 1/16W
R703 1-218-969-11 RES-CHIP 22K 5% 1/16W
< SWITCH >
S701 1-786-455-21 SWITCH, PUSH (1 KEY) (. –)
S704 1-771-851-41 SWITCH, TACTILE (SMD) (DISP)
S706 1-771-851-41 SWITCH, TACTILE (SMD) (Nx)
S707 1-786-863-21 SWITCH, PUSH (1 KEY) (GROUP/HOLD)
S708 1-786-862-21 SWITCH, PUSH (1 KEY) (> +)
S709 1-771-851-41 SWITCH, TACTILE (SMD) (SEARCH)
< VARISTOR >
VDR702 1-805-216-21 VARISTOR, CHIP
VDR703 1-805-216-21 VARISTOR, CHIP
VDR704 1-805-216-21 VARISTOR, CHIP
VDR705 1-805-216-21 VARISTOR, CHIP
************************************************************
MISCELLANEOUS
*************
BT901 X-2059-979-1 BATTERY, LITHIUM (ION) STORAGE (US,CND)
BT901 1-756-568-11 BATTERY, LITHIUM (ION) STORAGE
(EXCEPT US,CND)
J301 1-819-348-11 JACK
LCD901 1-805-849-11 INDICATOR MODULE, ORGANIC EL
MAIN SW
Ver. 1.4
