Sony PBD-D50 - Page 79

79
Additional Information
Outputs
Jack name
A/V
OUT
PCM/
MPEG/
DOLBY
DIGITAL
S VIDEO
OUT
PHONES
General
Power requirements
• Power supply jack
DC IN 10V jack accepts the AC-PBD1
AC power adapter (supplied),
AC 220-240 V, 50/60 Hz
• Battery pack (not supplied)
Power consumption
AC 220-240 V, 50 Hz, 0.18 A (max, AC
power adapter)
DC 10 V, 1.1 A (max, DVD VIDEO
playback with the AC power adapter)
Dimensions (approx.)
149.6 × 33.5 × 182.3 mm
(6 × 1
3
/
8
× 7
1
/
4
inches) (w/h/d)
Mass (approx.)
570 g (1 lb 4 oz) (unit only)
Operating temperature
5°C to 35°C (–41°F to 95°F)
Operating humidity
5 % to 80 %
Environment
Temperature
–20°C to 55°C (–4°F to 131°F)
Humidity
15 % to 90 % Rh
Jack type
Stereo
mini jack
Optical
output
connector
4-pin
mini DIN
Stereo
mini jack
Maximum
output
levels
1 Vrms
–17 dBm
Y: 1.0
Vp-p
C: 0.286
Vp-p
12 mV
+
12 mV
Load
impedance
Audio/Vrms
47 kilohms
Video/Vpp
75 ohms
terminated
Wave length:
660 nm
75 ohms sync
negative
75 ohms
terminated
16 ohms
SCSI PC card specifications
Operating temperature
5°C to 35°C (–41°F to 95°F)
Operating humidity
20 % to 80 % (no condensation)
Non-operating temperature
–20°C to 55°C (–4°F to 131°F)
Non-operating humidity
15 % to 90 % Rh (no condensation)
Acceptable interface
SCSI-2 based
MPC standard
MPC1, MPC2, MPC3 based
IC-PBD1 SCSI cable type PC card
Interface
PCMCIA 2.1 based
Card type
PCMCIA type II
Cable connected type
Half pitch pin type
50 pins
Cable length (approx.)
80 cm (31
1
/
2
inch)
DC current required
DC 5V about 80 mA
PC card dimensions (approx.)
54 × 85.6 × 5 mm
(2
1
/
4
× 3
3
/
8
×
7
/
32
inches) (w/h/d)
Mass (approx.)
28 g (1 oz)
Supplied accessories
See page 7.
Optional accessories
• Battery pack
NP-F750/F950
• AC battery changer
AC-V700
• DC battery changer
DC-V700
DC-V515
• Optical digital cable
POC-15B/15AB
• Headphones
MDR-605LP
Design and specifications are subject to
change without notice.
