1-3 (E)
PMW-EX1R
1-2. Location of the Printed Wiring Boards
1 ASW-68 board
2 AU-326 board
3 AXM-42 board
4 BI-202 board
5 BI-203 board
6 BI-204 board
7 CN-3258 board
8 CN-3259 board
9 CN-3273 board
0 DAP-41 board
!- DC-152 board
!= DET-52 board
![ DPR-311 board
!] DR-644 board
!\ EC-68 board
!; HN-356 board
!' HN-360 board
!, HN-361 board
!. HN-363 board
@/ IF-1127 board
@- KSW-55 board
@= LED-491 board
@[ LED-494 board
@] MA-183 board
@\ RE-272 board
@; RE-273 board
@' RM-224 board
@, SW-1478 board
@. SW-1484 board
#/ SWC-50 board
#- TX-131 board
#= VIF-46 board






















