Sony PRS-600 - Electronic Book Reader - Main Board Removal; FPC (Slot) Assembly Removal

PRS-600
5
2-5. MAIN BOARD
2-6. FPC (SLOT) ASSY
1
screw (M1.4)
7
MAIN board
6
five claws
5
FPC (jack) assy
flexible board
(CN102)
4
touch screen flexible board
(CN302)
2
FPC (slot) assy
flexible board
(CN301)
3
ink indicator element flexible board
(CN901)
top side
touch screen side
Note: Install the power switch (S101)
to fit to the knob_power.
power switch (S101)
knob_power
1 two shafts (washer head)
2 FPC (slot) assy flexible board
(CN301)
3 FPC (slot) assy
top side
touch screen side
