Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
– 7 –
1 4-950-497-01 FOOT SEAT
2 4-950-490-01 PLASTIC STAND
* 3 4-961-804-01 BUTTON BOARD
0 4 1-575-651-61 CORD, POWER (AEP,EA,MX)
0 4 1-590-074-11 CORD, POWER (E)
0 4 1-690-608-11 CORD, POWER (AUS)
0 4 1-696-570-21 CORD, POWER (UK)
5 1-555-116-11 CORD, PHONE
6 4-236-539-01 BUTTON, SPEED
7 4-236-538-01 BUTTON, REJECT
8 4-236-540-01 BUTTON, POWER
* 9 4-947-487-01 RETURN LINK
10 4-890-173-00 WASHER
11 3-659-350-00 WASHER
12 A-4604-947-A RETURN ASSY, LEVER
13 4-947-485-01 SPRING (22)
14 4-947-510-01 NUT
15 4-947-491-01 ARM REST
16 A-4660-499-A ARM CLIP ASSY
17 4-947-477-01 CUEING (BASE)
18 4-947-468-01 LEVER, CUEING
19 4-963-537-01 SPRING
20 4-963-536-01 LINK, RETURN
21 4-963-535-01 CAM, ADJUST
22 4-947-514-01 4MM CS RING
23 4-947-467-01 SPRING (6)
24 4-947-466-01 TONE ARM ELEVATOR
25 A-4660-498-A HINGE ASSY
26 A-4735-409-A FRONT PANEL ASSY
27 4-236-537-01 CABINET, MAIN
28 4-947-505-01 CUSHION MOTOR
29 4-947-504-01 COLLAR
30 3-451-162-00 WASHER (56)
31 3-701-445-21 WASHER
32 4-947-498-01 STELL BALL
33 4-947-497-01 GEAR
34 4-947-496-01 SPRING (34)
35 4-947-495-01 WIPER REJECT
36 4-948-101-01 SPRING (38)
37 A-4604-916-A GEAR ASSY, SPUR
38 4-947-503-01 BELT
39 4-947-494-01 TURNTABLE PLATTER
40 4-947-539-01 RUBBER MAT
41 A-4604-946-A DUST COVER ASSY
* 42 1-652-482-11 PHONO BOARD
43 4-948-095-01 COVER, CARTRIDGE
44 4-951-290-01 STYLUS (CN-234)
45 A-4604-940-A ARM ASSY, TONE
46 4-947-464-01 COUNTER WEIGHT
47 4-952-961-01 SCREW
* 48 1-649-845-11 RELAY BOARD
49 3-701-806-00 ADAPTOR, 45
M1 A-4604-945-A MOTOR ASSY (INCLUDING PULLEY)
SW1 1-570-666-11 SWITCH (LEAF) (MOTOR ON/OFF)
SW2 1-571-089-11 SWITCH, PUSH (SPEED) (1 KEY)
SW3 1-692-211-11 SWITCH, PUSH (POWER) (1 KEY)
0 SW4 1-692-835-11 VOLTAGE SELECTOR (AUS, E, MX)
0 T1 1-450-987-11 TRANSFORMER, POWER (AEP, UK)
0 T1 1-450-987-21 TRANSFORMER, POWER (AUS, E, EA, MX)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
