Ref. No. Part No. Description Remarks
– 8 –
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• AUS : Australian model
• MX : Mexican model
• EA : Saudi Arabia model
• Due to standardization, replacements in the parts
list may be different from the parts specified in the
diagrams or the components used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
ELECTRICAL PARTS LIST
Note:
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
PHONO
RELAY
* 1-652-482-11 PHONO BOARD
***********
*
4-962-076- FUSE CLAMP
<CAPACITOR>
C1 1-126-012-11 ELECT 470uF 20% 16V
<DIODE>
D1 8-719-200-82 DIODE 11ES2
D2 8-719-200-82 DIODE 11ES2
D3 8-719-200-82 DIODE 11ES2
D4 8-719-200-82 DIODE 11ES2
<FUSE>
0 F1 1-532-387-51 FUSE, CYLINDRICAL (TIME-LAG) (T200mA)
******************************************************
*
1-649-845-11 RELAY BOARD
***********
******************************************************
MISCELLANEOUS
*************
0 4 1-575-651-61 CORD, POWER (AEP)
0 4 1-590-074-11 CORD, POWER (E)
0 4 1-690-608-11 CORD, POWER (AUS)
0 4 1-696-570-21 CORD, POWER (UK)
5 1-555-116-11 CORD, PHONE
M1 A-4604-945-A MOTOR ASSY (INCLUDING PULLEY)
SW1 1-570-666-11 SWITCH (LEAF) (MOTOR ON/OFF)
SW2 1-571-089-11 SWITCH, PUSH (SPEED) (1 KEY)
SW3 1-692-211-11 SWITCH, PUSH (POWER) (1 KEY)
0 SW4 1-692-835-11 VOLTAGE SELECTOR (AUS, E, MX)
0 T1 1-450-987-11 TRANSFORMER, POWER (AEP, UK)
0 T1 1-450-987-21 TRANSFORMER, POWER (AUS, E, EA, MX)
******************************************************
ACCESSORIES & PACKING MATERIALS
****************************
3-701-806-00 ADAPTOR, 45
3-758-045-11 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, PORTUGUESE) (AEP)
3-758-045-21 MANUAL, INSTRUCTION (ENGLISH) (UK)
3-758-045-41 MANUAL, INSTRUCTION
(GERMAN, DUTCH, SWEDISH, ITALIAN) (AEP)
3-758-045-51 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, CHINESE) (AUS, E, MX, EA)
* 4-947-532-01 SNOW BOX (L)
* 4-947-533-01 SNOW BOX (R)
4-947-539-01 RUBBER MAT
******************************************************
*************
HARDWARE LIST
*************
#1 7-621-773-87 SCREW (64)
#2 7-623-210-22 WASHER (57)
#3 7-624-110-04 6MM E RING
#4 7-685-105-01 SCREW (59)
#5 7-685-645-79 SCREW (68)
#6 7-685-646-79 SCREW (60)
#7 7-685-647-79 SCREW (58)
#8 7-688-005-01 WASHER (69)
To Next Page
