Sony RDP-XA700iP User Manual

12
US
Connecting Your Network
See the following descriptions to determine the correct way to set up.
Option 1: Wi-Fi Connection using
WPS Push Button Configuration
Method
Setup device: Wireless LAN router/access
point
Refer to A in the supplied “AirPlay via Wi-Fi
Network Setup” for details.
Option 2: Wi-Fi Connection using
D-Sappli*
Setup device: iPhone/iPod touch/iPad
Refer to B in the supplied “AirPlay via Wi-Fi
Network Setup” for details.
* For details on D-Sappli, see page 16.
Option 3: Wi-Fi Connection using
Access Point Scan (page 13)
Setup device: Mac or PC
Option 4: Wired Connection
Connect the unit and a wireless LAN router/
access point by network (LAN) cable (not
supplied). Then turn this unit on.
The LINK indicator lights up amber when the
connection is established (about 90 seconds
later).
Connecting to a Wi-Fi network Connecting to a wired network

Sony RDP-XA700iP Specifications

General

Product color	Black
Volume control	Digital
Indication light	Yes
Dimensions (WxDxH)	401 x 176 x 160 mm
Impedance	8 Ω
Driver diameter	48 mm
Frequency range	- Hz
RMS rated power	60 W
Audio output channels	2.1 channels
Bluetooth	No
Headphone connectivity	-
Apple docking compatibility	iPad, iPhone, iPod
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 Hz

Weight and Dimensions

Depth	160 mm
Width	401 mm
Height	176 mm
Weight	3300 g
